AsiaRF AP2620
From TechInfoDepot
Jump to navigationJump to search
bgn (N300) | |
---|---|
wireless router | |
![]() | |
3rd Party Firmware | |
dd-wrt | Status Unknown |
OpenWrt | Not Supported |
Tomato any flavor | Incompatible |
Platform | |
Brand • Model • Rev | AsiaRF AP2620 |
FCC ID | none specified |
Type | wireless router |
CPU1 ![]() | MediaTek MT7620A |
CPU1 Type | MIPS 24KEc |
CPU1 Speed | 580 MHz 32-bit |
Flash1 Chip | Brand? Model? |
Flash1 Size | 8 MiB8,388,608 B <br />65,536 Kib <br />8,192 KiB <br />64 Mib <br />0.00781 GiB <br /> |
RAM1 Size | 32 MiB33,554,432 B <br />262,144 Kib <br />32,768 KiB <br />256 Mib <br />0.0313 GiB <br /> |
RAM1 Chip | Brand? Model? |
ETH chip1 | MediaTek MT7620A |
Ethernet Port Count | 1-100MbE-WAN1-100MbE-LAN |
Wired Standard | IEEE 802.3i/3u |
802dot11 OUI: none specified | |
Expansion IF types | USB 2.0 |
USB ports | 1 |
USB Hub Compatible | Untested |
| |
Radio 1 | |
Chip1 | MediaTek MT7620A |
Wireless interface OUI | none specified |
Antenna Connector Type | none specified |
MIMO status | 2x2:2 |
Wireless Standard | IEEE 802.11b/g/n |
802.11n | up to 300 Mbps |
802.11g | up to 54 Mbps |
802.11b | up to 11 Mbps |
WiFi Operating Frequency | 2.4 GHz |
For a list of all currently documented MediaTek chipsets with specifications, see MediaTek.
For a list of all currently documented AsiaRF devices with specifications, see AsiaRF.
- • 300 Mbps - 2SS 2.4GHz 802.11n (40MHz chan.) = N300 class
Flashing
![]() | NOTE: During configuration or flashing a device, the only things that should be hooked to the device is the computer and power. |
Flashing OpenWrt
![]() | This device is NO LONGER SUPPORTED OR POSSIBLE for future use with OpenWrt. |
On the OpenWrt ToH (techdata entry)
On the OpenWrt Wiki
OpenWrt Target: ramips
OpenWrt Subtarget: mt7620
OpenWrt Package architecture: mipsel_24kc
Support started version: Never supported
Current supported version: Never supported
Unsupported Functions:
Never supported
On the OpenWrt Wiki
OpenWrt Target: ramips
OpenWrt Subtarget: mt7620
OpenWrt Package architecture: mipsel_24kc
Support started version: Never supported
Current supported version: Never supported
Unsupported Functions:
Never supported
Please insert instructions here
