AzureWave AW-GA800BT
From TechInfoDepot
Jump to navigationJump to search
| bg (G54) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 802.11b/g USB 2.0 Wireless Module | ||||||||||
|
| ||||||||||
| Homepage | Product page | |||||||||
| WikiDevi.wi-cat.ru | AzureWave AW-GA800BT | |||||||||
| Platform | ||||||||||
| Brand • Model • Rev | AzureWave AW-GA800BT | |||||||||
| Interface | USB 2.0 | |||||||||
| Connector | (non-standard connector) | |||||||||
|
| ||||||||||
|
| ||||||||||
| FCCID | TLZ-800BT | |||||||||
| ICID | 6100A-800BT | |||||||||
|
| ||||||||||
| Chip1 | Realtek RTL8187L | |||||||||
| Chip2 | Realtek RTL8225 | |||||||||
| Antenna Connection | RP-SMA | |||||||||
| Wireless Standards | IEEE 802.11b/g | |||||||||
| 802.11g | up to 54 Mbps | |||||||||
| 802.11b | up to 11 Mbps | |||||||||
| Operating Frequency | 2.4 GHz | |||||||||
|
Additional chips | ||||||||||
|
Probable Linux driver | ||||||||||
|
Windows driver | ||||||||||
| Retail | ||||||||||
| FCC approval date | 05 May 2006 | |||||||||
| ||||||||||
For a list of all currently documented Realtek chipsets with specifications, see Realtek.
For a list of all currently documented AzureWave devices with specifications, see AzureWave.
- • 54 Mbps - 2.4GHz 802.11g = G54 class
Overview
- Wi-Fi Certified : WFA4402 (as of 05/18/2006)
Links of Interest
Forum threads
- used in ASUS P5W DH Deluxe MB
- used in Asus P5N32 SLI Premium MB
- AzureWave_AW-NA830 802.11bgn 1x2:2
- Drivers RTL8187L
- Power and USB pin
+3VSB NC GND D1+ D1- +5v USB ------------------------- | o | o | o | o | o | o | ------------------------- | o | x | o | o | o | © | 1 ------------------------- PME# key GND D0+ D0- +5v USB
