AzureWave AW-NE769
From TechInfoDepot
Jump to navigationJump to search
| bgn (N150) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| WLAN PCIe Wifi Card 802.11 b/g/n | |||||||||||
|
| |||||||||||
| Platform | |||||||||||
| Brand • Model • Rev | AzureWave AW-NE769 | ||||||||||
| Interface | PCIe | ||||||||||
| Connector | PCIe | ||||||||||
|
| |||||||||||
|
| |||||||||||
| FCCID | VQF-RT2700E | ||||||||||
|
| |||||||||||
| Chip1 | Ralink RT2790 | ||||||||||
| Chip2 | Ralink RT2720 | ||||||||||
| Antenna Connection | RP-SMA | ||||||||||
| MIMO status | 1x2:2 | ||||||||||
| Wireless Standards | IEEE 802.11b/g/n | ||||||||||
| 802.11n | up to 150 Mbps | ||||||||||
| 802.11g | up to 54 Mbps | ||||||||||
| 802.11b | up to 11 Mbps | ||||||||||
| Operating Frequency | 2.4 GHz | ||||||||||
|
| |||||||||||
|
Probable Linux driver | |||||||||||
|
Windows driver | |||||||||||
| Retail | |||||||||||
| FCC approval date | 12 November 2007 | ||||||||||
| |||||||||||
For a list of all currently documented Ralink chipsets with specifications, see Ralink.
For a list of all currently documented AzureWave devices with specifications, see AzureWave.
- • 150 Mbps - 1SS 2.4GHz 802.11n (40MHz chan.) = N150 class
Overview
Appears to be a Mini PCIe card on a Mini PCIe to PCIe converter.
