Broadcom BCM943602BAED
From TechInfoDepot
Jump to navigationJump to search
abgn+ac (AC1750) | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
802.11abgn/ac 3x3 WLAN + Bluetooth PCI-E Card | |||||||||||||
WikiDevi.wi-cat.ru | Broadcom BCM943602BAED | ||||||||||||
Platform | |||||||||||||
Brand • Model • Rev | Broadcom BCM943602BAED | ||||||||||||
Series | BCM943602 | ||||||||||||
Interface | M.2 2.0 | ||||||||||||
Connector | M.2 | ||||||||||||
Form factor | 3030 | ||||||||||||
ID:14e4:aa52 Windows: PCI\VEN_14E4&DEV_AA52 | |||||||||||||
FCCID | QDS-BRCM1088 | ||||||||||||
ICID | 4234A-BRCM1088 | ||||||||||||
Chip1 | Broadcom BCM43602 | ||||||||||||
OUI: none specified | |||||||||||||
Antenna Connection | MHF4 | ||||||||||||
MIMO status | 3x3:3 | ||||||||||||
Wireless Standards | IEEE 802.11a/b/g/n/ac | ||||||||||||
802.11ac | up to 1300 Mbps | ||||||||||||
802.11n | up to 450/450 Mbps | ||||||||||||
802.11g | up to 54 Mbps | ||||||||||||
802.11b | up to 11 Mbps | ||||||||||||
802.11a | up to 54 Mbps | ||||||||||||
Operating Frequency | 2.4 or 5 GHz | ||||||||||||
Other | |||||||||||||
Flags: Bluetooth 4.1 LE | |||||||||||||
Additional chips | |||||||||||||
Probable Linux driver | |||||||||||||
Retail | |||||||||||||
Availability | reference design | ||||||||||||
FCC approval date | 02 July 2015 | ||||||||||||
Country of manuf | China | ||||||||||||
| |||||||||||||
|
For a list of all currently documented Broadcom chipsets with specifications, see Broadcom.
For a list of all currently documented Broadcom devices with specifications, see Broadcom.
Overview
- FCC ID: QDS-BRCM1088 • IC Doc
This device was under short-term confidentiality, but that expired 02/23/2016 ⚠.
See also: Dell Wireless 1830 (DW1830)
Links of Interest
Forum threads
- On AppleLife forums
- On InsanelyMac forums
- Skvo notes the pinout of the connector used on Tonymacx86 forums
- Broadcom BCM943602BAED on tonymacx86 forums
- Broadcom BCM943602BAED (Dell DW1830)
- NGFF M.2 Key A+E, 14e4:43ba, 3x3:3 MIMO
- Bluetooth: BCM20703A1 (BCM2045A0), 0a5c:6410
- Broadcom BCM943602BAED (14e4:43ba, 14e4:aa52)
Notes
Specifications
- Broadcom BCM943602BAED 802.11abgn/ac + BT 4.1, 3x3, 2.4/5 GHz (Key A+E)
- Based on BCM's naming scheme, this device is assumed to be using BCM43602.
- Broadcom News Release for BCM43602
- Broadcom BCM43602 - Vendor ID: 0x14e4, DeviceID: 0x43ba
- BCM43602 14e4:43ba supported in 3.17+ (brcmfmac)
- BCM43602 14e4:43bb 2.4GHz device, supported in 3.19+
- BCM43602 14e4:43bc 5GHz device, supported in 3.19+
- Broadcom BCM20703A1 (chipset support BT 4.1 LE)
Windows driver
Broadcom 802.11ac Wireless PCIE Full Dongle Adapter
Broadcom 802.11ac Wireless PCIE Full Dongle Adapter 14e4:43a3 (BCM4350) Broadcom 802.11ac Wireless PCIE Full Dongle Adapter 14e4:43ba (BCM43602) Broadcom 802.11ac Wireless PCIE Full Dongle Adapter 14e4:43c3 (BCM4366) Broadcom 802.11ac Wireless PCIE Full Dongle Adapter 14e4:43ec (BCM4356) Broadcom 802.11ac Wireless PCIE Full Dongle Adapter 14e4:43ef (BCM4359) Broadcom 802.11ac Wireless PCIE Full Dongle Adapter 14e4:440d (BCM4371) Broadcom 802.11ac Wireless PCIE Full Dongle Adapter 14e4:aa31 Broadcom 802.11ac Network Adapter (BCM943602BAED) 14e4:aa52 (BCM43602)
See also
- Dell Wireless 1830 (DW1830) - Broadcom BCM43602
- BT: Broadcom BCM20703A1 (DW1830 Bluetooth 4.1 LE)
