MitraStar QTN5X40BD-AC
From TechInfoDepot
Jump to navigationJump to search
an+ac (AC1800) | |||||
---|---|---|---|---|---|
Platform | |||||
Brand • Model • Rev | MitraStar QTN5X40BD-AC | ||||
Interface | Mini PCIe | ||||
Connector | Mini PCIe | ||||
Form factor | (oversized) | ||||
FCCID | I88WAP6806 | ||||
Chip1 | Quantenna QT3840BC | ||||
Chip2 | Quantenna QT2518B | ||||
OUI: none specified | |||||
Antenna Connection | U.FL | ||||
MIMO status | 4x4:4 | ||||
Wireless Standards | IEEE 802.11a/n/ac | ||||
802.11ac | up to 1733 Mbps | ||||
802.11n | up to 600 Mbps | ||||
802.11a | up to 54 Mbps | ||||
Operating Frequency | 5 GHz | ||||
Other | |||||
Manuf/OEM/ODM | MitraStar | ||||
Flags: 256QAM | |||||
Probable Linux driver | |||||
Retail | |||||
FCC approval date | 31 May 2016 | ||||
Country of manuf | China | ||||
|
For a list of all currently documented Quantenna chipsets with specifications, see Quantenna.
For a list of all currently documented MitraStar devices with specifications, see MitraStar.
- • 1733 Mbps - 4SS 5GHz 802.11ac (80MHz chan.) = AC1800 class
