Realtek RTL8821CE Combo Module
From TechInfoDepot
Jump to navigationJump to search
abgn+ac (AC600) | |
---|---|
802.11abgn/ac RTL8821CE Combo Module | |
Platform | |
Brand • Model • Rev | Realtek RTL8821CE Combo Module |
Interface | Mini PCIe 1.1 |
Connector | M.2 |
Form factor | 2230 |
ID:10ec:c821 SS: 103c:831a | |
| |
FCCID | TX2-RTL8821CE |
ICID | 6317A-RTL8821CE |
Board ID | U98H132 |
Chip1 | Realtek RTL8821CE |
OUI: none specified | |
Antenna Connection | U.FL |
MIMO status | 1x1:1 |
Wireless Standards | IEEE 802.11a/b/g/n/ac |
802.11ac | up to 433 Mbps |
802.11n | up to 150 Mbps |
802.11g | up to 54 Mbps |
802.11b | up to 11 Mbps |
802.11a | up to 54 Mbps |
Operating Frequency | 2.4 or 5 GHz |
Other | |
Manuf/OEM/ODM | Foxconn U98H132 .00 |
Flags: | |
| |
Windows driver | |
Retail | |
Availability | reference design |
FCC approval date | 12 December 2016 |
Country of manuf | China |
For a list of all currently documented Realtek chipsets with specifications, see Realtek.
For a list of all currently documented Realtek devices with specifications, see Realtek.
Overview
See also: Realtek reference design
- Realtek RTL8821CE - PCIe 1.1 (WLAN)/USB 2.0 (BT)
- 802.11abgn+ac 1T1R (1x1:1), Wave2, MU-MIMO, BT 4.2
- 802.11abgn/ac RTL8821CE Combo Module
- FCC ID: TX2-RTL8821CE (2016-12-12)
- IC: 6317A-RTL8821CE; 3.3V/0.5A
- Lenovo notebook models:
- Lenovo IdeaPad S540-14IWL Touch (81QX),
- S540-14IWL (81ND), S540-14API (81NH),
- C340-14IWL (81N4), FLEX-14IWL (81SQ),
- C340-14API (81N6), FLEX-14API (81SS)
- Lenovo ThinkPad E570, 720S-13ARR
- HP All-in-One • [10ec:c821/103c:831a]
- Lenovo ThinkPad E570 • [10ec:c821/17aa:c024]
#root@HP:~# lspci -nnk | grep -A2 0280 Network controller [0280]: Realtek Semiconductor Co., Ltd. RTL8821CE 802.11ac PCIe Wireless Network Adapter [10ec:c821] Subsystem: Hewlett-Packard Company RTL8821CE 802.11ac PCIe Wireless Network Adapter [103c:831a] #root@ThinkPad-E570:~# lspci -nnk | grep 0280 -A3 Network controller [0280]: Realtek Semiconductor Co., Ltd. Device [10ec:c821] Subsystem: Lenovo Device [17aa:c024]
#ifdef CONFIG_RTL8821C {PCI_DEVICE(PCI_VENDER_ID_REALTEK, 0xC821), .driver_data = RTL8821C}, {PCI_DEVICE(PCI_VENDER_ID_REALTEK, 0xC82A), .driver_data = RTL8821C}, {PCI_DEVICE(PCI_VENDER_ID_REALTEK, 0xC82B), .driver_data = RTL8821C},
See also
- Realtek RTL8821AE Combo Module (10ec:8821)
- 802.11abgn/ac RTL8821AE Combo Module
- FCC ID: TX2-RTL8821AE (2013-07-10)
- 802.11abgn/ac RTL8821AU Combo Module
- FCC ID: TX2-RTL8821AU (2014-03-06)
- Realtek RTL8821CE Combo Module (10ec:c821)
- 802.11abgn/ac RTL8821CE Combo Module
- FCC ID: TX2-RTL8821CE (2016-12-12)
