SparkLAN WNFQ-291BEI (BT)

abgn+ac+ax+be (BE6500)
BE6500 Wi-Fi 7 Tri-Band Wireless PCIe Adapter
Homepage	Product page
WikiDevi.wi-cat.ru	SparkLAN WNFQ-291BEI (BT)
Platform
Brand • Model • Rev	SparkLAN WNFQ-291BEI (BT)
Interface	NGFF 2.1
Connector	M.2
Form factor	2230 (Key E)
ID:17cb:1107 (2 addl. devices) Windows: PCI\VEN_17CB&DEV_1107
FCC ID	RYK-WNFQ291BEBT, J9C-QCNCM865, JCK-QCNCM865
FCC ID (fcc.report)	RYK-WNFQ291BEBT, J9C-QCNCM865, JCK-QCNCM865
Chip1	Qualcomm WCN7851
OUI: none specified
Antenna Connection	MHF4
MIMO status	2x2:2
Wireless Standards	IEEE 802.11a/b/g/n/ac/ax/be
802.11be	up to 2402 Mbps
AX-QAM	up to 1201 Mbps
802.11ax	up to 574 Mbps
802.11ac	up to 867 Mbps
802.11n	up to 300 Mbps
802.11g	up to 54 Mbps
802.11b	up to 11 Mbps
802.11a	up to 54 Mbps
Operating Frequency	2.4 or 5 or 6 GHz
Other
Flags: Wi-Fi 7, Bluetooth 5.4, BW320, 4K-QAM, WPA3, MRU, MLO
Probable Linux driver ath12k (see also passys)
Windows driver Win 11
Retail
FCC approval date	28 October 2024
Country of manuf	China
FCC ID Gigabyte AORUS GC-WIFI7 J9C-QCNCM865 RAS-MT7927 PD9BE200NG JCK-QCNCM865 Qualcomm QCNCM865 J9C-QCNCM865 JCK-QCNCM865   FCC ID Gigabyte AORUS GC-WIFI7 J9C-QCNCM865 RAS-MT7927 PD9BE200NG JCK-QCNCM865 Qualcomm QCNCM865 J9C-QCNCM865 JCK-QCNCM865

For a list of all currently documented Qualcomm chipsets with specifications, see Qualcomm.

For a list of all currently documented SparkLAN devices with specifications, see SparkLAN.

• 688 Mbps - 2SS 2.4GHz 802.11be (40MHz chan.),

• 5765 Mbps - 4SS 5/6GHz 802.11be (160MHz chan., 4K-QAM) = BE6500 class

Overview

See also: Qualcomm Atheros reference design and SparkLAN

• Qualcomm QCNCM865 • BE6500 • Qualcomm WiFi 7/BT Combo Module

FCC ID: J9C-QCNCM865 (2023-04-05) • Qualcomm WCN7851 (Hamilton)

• Gigabyte AORUS GC-WIFI7 • Wi-Fi 7 PCIe WLAN Card (BE6500) • PPage

FCC ID: JCK-QCNCM865 (2023-08-16) • Qualcomm WCN7851 (Hamilton)

#define QCS405 PCIe_Root_Complex	17cb:1000
#define QCA6290 VENDOR/DEVICE_ID	17cb:1100
#define QCA6390 VENDOR/DEVICE_ID	17cb:1101
#define WCN6856 (QCNFA765)		17cb:1103
#define QCN6024/QCN9024/QCN9074		17cb:1104
#define WCN785x (FastConnect 7800)	17cb:1107
#define IPQ9574/IPQ97xx (PCIe port)	17cb:1108
#define QCN6274/QCN9274/IPQ5332		17cb:1109
#define IPQ5404/IPQ5414/IPQ5424		17cb:1112 ?
