| bgn (N300) | |
|---|---|
| N300 Wireless Universal Range Extender | |
 | |
| Support | Support page |
| WikiDevi.wi-cat.ru | Tenda A9 |
| 3rd Party Firmware | |
| dd-wrt | Incompatible |
| OpenWrt | Incompatible |
| Tomato any flavor | Incompatible |
| Platform | |
| Brand • Model • Rev | Tenda A9 V1.2 |
| FCC ID | V7TA9 |
| IC ID | 9034A-A9 |
| Board ID | 10029487 |
| Type | range extender, repeater |
CPU1  | Realtek RTL8196EU |
| CPU1 Type | Lexra RLX4181 |
| CPU1 Speed | 400 MHz |
| Flash1 Chip | GigaDevice MD25D80SIG |
| Flash1 Size | 1 MiB1,048,576 B <br />8,192 Kib <br />1,024 KiB <br />8 Mib <br />9.765625e-4 GiB <br /> |
| RAM1 Size | 8 MiB8,388,608 B <br />65,536 Kib <br />8,192 KiB <br />64 Mib <br />0.00781 GiB <br /> |
| RAM1 Chip | Winbond W9864G6KH-6 |
|
802dot11 OUI: none specified | |
| Expansion IF types | none specified |
| Power | 100-240 VAC ~ 50/60 Hz, 0.3 A |
| Connector type | AC (direct) |
| Serial Port (UART) | yes, 4-pin header, J1 |
|
| |
|
| |
| Other | |
|
Default IP address: 192.168.0.254 | |
| Manuf/OEM/ODM | Tenda |
| Retail | |
| FCC approval date | 21 July 2016 |
| Country of manuf | China |
| Radio 1 | |
| Chip1 | Realtek RTL8192ER |
| Wireless interface OUI | none specified |
| Antenna Connector Type | none specified |
| MIMO status | 2x2:2 |
| Wireless Standard | IEEE 802.11b/g/n |
| 802.11n | up to 300 Mbps |
| 802.11g | up to 54 Mbps |
| 802.11b | up to 11 Mbps |
| WiFi Operating Frequency | 2.4 GHz |
For a list of all currently documented Realtek chipsets with specifications, see Realtek.
For a list of all currently documented Tenda devices with specifications, see Tenda.
- • 300 Mbps - 2SS 2.4GHz 802.11n (40MHz chan.) = N300 class
Overview
"10029487" and "V1.2" is silkscreened on the board.
See also: Tenda and Tenda PCB ID
- Web GUI: http://re.tenda.cn
Teardown
- CPU: Realtek RTL8196E @400MHz
- Flash: GigaDevice MD25D80SIG (1MB)
- RAM: Winbond W9864G6KH-6 (8MB)
- Wi-Fi: Realtek RTL8192ER (2T2R)
Links of Interest
Models
- Tenda A9 (v1) • Wireless N300 Range Extender
- FCC ID: V7TA9 (2016-07-21)
- Tenda A9 v2 • Wireless N300 Range Extender
- FCC ID: V7TA9V2 (2019-05-27)
- Tenda A9 v3 • Wireless N300 Range Extender
- FCC ID: V7TA9V3 (2021-05-17)
- Tenda A9 v4 • N300 Wi-Fi Range Extender
- FCC ID: V7TA9V4 (2025-11-19)
