Devices
See also: List of 802.11be Hardware
Wireless Adapters BE series
| Device | Interface | PHY modes |
Manuf. | Chip1 | Chip2 | MIMO | Addl. info |
FCC date |
|---|---|---|---|---|---|---|---|---|
| Intel Wi-Fi 7 BE200 (BE200NGW) FCC ID: PD9BE200NG has external images |
USB 2.0 2230 [Key E], M.2 |
abgn+ac+ax+be BE6500 8086:272b |
CoO:
|
Intel WCSBE200 |
2x2:2 iwlwifi |
Ant. conn: MHF4 Flags: Wi-Fi 7, EHT320, MU-MIMO, DFS (slave), Bluetooth 5.4, 4K-QAM |
2023-08-15 | |
| Intel Wi-Fi 7 BE201 (BE201NGW) FCC ID: PD9BE201NG has external images |
NGFF CNVio 2230 [Key E], M.2 (CNVio) |
abgn+ac+ax+be BE65003R 8086:272b |
CoO:
|
Intel WCSBE201 |
2x2:2 iwlwifi |
Ant. conn: MHF4 Flags: Wi-Fi 7, EHT320, MU-MIMO, 1024QAM, CNVio, DFS (slave), Bluetooth 5.4 |
2024-05-06 | |
| Intel Wi-Fi 7 BE202 (BE202NGW) has external images |
USB 2.0 2230 [Key E], M.2 |
abgn+ac+ax+be BE3600 8086:272b |
CoO:
|
Intel WCSBE202 |
2x2:2 iwlwifi |
Ant. conn: MHF4 Flags: Wi-Fi 7, EHT160, MU-MIMO, DFS (slave), Bluetooth 5.4, 4K-QAM |
2023-01-01 (no FCC) |
Models
- Intel Wi-Fi 7 BE200 320MHz [Gale Peak 2] • Wi-Fi 7 2x2 • PCIe/USB
- Intel Wi-Fi 7 BE200 (BE200NGW) • (M.2 2230) • [8086:272b/8086:00f0] • Spec.
- • FCC ID: FCC ID: PD9BE200NG (2023-08-15)
- Intel Killer Wi-Fi 7 BE1750x 320MHz (BE200NGW) • [8086:272b/1a56:1774]
- Intel Wi-Fi 7 BE200 (BE200D2W) • (M.2 1216) • [8086:272b/8086:00f4] • Spec.
- • FCC ID: FCC ID: PD9BE200D2 (2023-08-14)
- Intel Killer Wi-Fi 7 BE1750w 320MHz (BE200D2W) • [8086:272b/1a56:1773]
- Intel Wi-Fi 7 BE201 320MHz [Fillmore Peak 2] • Wi-Fi 7 2x2 • CNVio3
- Intel Wi-Fi 7 BE201 (BE201NGW) • (M.2 2230) • [8086:272b] • PBrief
- Intel Killer Wi-Fi 6 AX1775i 320MHz (BE201NGW)
- Intel Wi-Fi 7 BE201 (BE201D2W) • (M.2 1216) • SD ("Lunar Lake")
- Intel Killer Wi-Fi 6 AX1775s 320MHz (BE201D2W) •
- Intel Wi-Fi 7 BE202 160MHz [Misty Peak 2] • Wi-Fi 7 2x2 • PCIe/USB
- Intel Wi-Fi 7 BE202 (BE202NGW) • (M.2 2230) • [8086:272b/8086:02f4] (42f4)
- Intel Wi-Fi 7 BE211 320MHz [Whale Peak 2] • Wi-Fi 7 2x2 • CNVio3
- Intel Wi-Fi 7 BE211 (BE211NGW) • (M.2 2230) • [8086:e440/8086:0114]
- Intel Killer Wi-Fi 7 BE1775i 320MHz (BE211NGW) • No vPro, BT 6.0
- Intel Wi-Fi 7 BE401 320MHz [Fillmore Peak 2] • Wi-Fi 7 2x2 • CNVio3
- Intel Wi-Fi 7 BE401 (BE401NGW) • (M.2 2230) • [8086:272b]
- Intel Killer Wi-Fi 6 AX1790i 320MHz (BE401NGW) •
- Intel Wi-Fi 7 BE401 (BE401D2W) • (M.2 1216) • SD
- Intel Killer Wi-Fi 6 AX1790s 320MHz (BE401D2W) •
| Wi-Fi 7 Models • >> |
|---|
PCI ID: 8086:272b (BE20*/BE401/BE1750*/AX1775*/AX1790* 2x2)
8086:272b 8086 00f0 BE200 320MHz [Gale Peak]
8086:272b 8086 00f4 BE200 320MHz [Gale Peak]
8086:272b 8086 40f0 BE200 320MHz [Gale Peak]
8086:272b 8086 e0f4 BE200 320MHz [Gale Peak]
8086:272b 8086 02f4 BE202 160MHz [Misty Peak]
8086:272b 8086 42f4 BE202 160MHz [Misty Peak]
<BE20x/BE40x/BE17xx>
*Intel Wi-Fi 7 BE200 320MHz
:Killer Wi-Fi 7 BE1750x 320MHz Wireless Network Adapter (BE200NGW)
:Killer Wi-Fi 7 BE1750w 320MHz Wireless Network Adapter (BE200D2W)
*Intel Wi-Fi 7 BE201 320MHz
:Killer Wi-Fi 6 AX1775i 320MHz Wireless Network Adapter (BE201NGW)
:Killer Wi-Fi 6 AX1775s 320MHz Wireless Network Adapter (BE201D2W)
*Intel Wi-Fi 7 BE202 160MHz
*Intel Wi-Fi 7 BE401 320MHz
:Killer Wi-Fi 6 AX1790i 320MHz Wireless Network Adapter (BE401NGW)
:Killer Wi-Fi 6 AX1790s 320MHz Wireless Network Adapter (BE401D2W)
{{----}}
<AX2xx/AX4xx>
*Intel Wi-Fi 6 AX200 160MHz
:Killer Wi-Fi 6 AX1650x 160MHz Wireless Network Adapter (200NGW)
:Killer Wi-Fi 6 AX1650w 160MHz Wireless Network Adapter (200D2W)
*Intel Wi-Fi 6E AX210 160MHz
:Killer Wi-Fi 6E AX1675x 160MHz Wireless Network Adapter (210NGW)
:Killer Wi-Fi 6E AX1675w 160MHz Wireless Network Adapter (210D2W)
*Intel Wi-Fi 6E AX211 160MHz
:Killer(R) Wi-Fi 6E AX1675i 160MHz Wireless Network Adapter (211NGW)
:Killer(R) Wi-Fi 6E AX1675s 160MHz Wireless Network Adapter (211D2W)
*Intel Wi-Fi 6E AX411 160MHz
:Killer Wi-Fi 6E AX1690i 160MHz Wireless Network Adapter (411NGW)
:Killer Wi-Fi 6E AX1690s 160MHz Wireless Network Adapter (411D2W)
{{----}}
<9xxx>
*Intel Wireless-AC 9560 • Intel Wireless-AC 9560 160MHz
:Killer Wireless-AC 1550i Wireless Network Adapter (9560NGW) 160MHz
:Killer Wireless-AC 1550s Wireless Network Adapter (9560D2W) 160MHz
*Intel Wireless-AC 9462 • Intel Wireless-AC 9462 160MHz
*Intel Wireless-AC 9461 • Intel Wireless-AC 9461 160MHz
*Intel Wireless-AC 9260 • Intel Wireless-AC 9260 160MHz
:Killer Wireless-AC 1550 Wireless Network Adapter (9260NGW) 160MHz
<3165/3168/7265>
*Intel(R) Dual Band Wireless-AC 3165
*Intel(R) Dual Band Wireless-AC 3168
*Intel(R) Dual Band Wireless-AC 7265
*Intel(R) Dual Band Wireless-N 7265
:;Code IDs
PCI\VEN_8086&DEV_272B='Intel(R) Wi-Fi 7 BE' • Wi-Fi 7 (802.11be) AX1775*/AX1790*/BE20*/BE401/BE1750* 2x2 + (√)
PCI\VEN_8086&DEV_2725='Intel(R) Wi-Fi 6E AX210' • Wi-Fi 6E (802.11ax) AX210/AX1675* 2x2 [Typhoon Peak]+
PCI\VEN_8086&DEV_2723='Intel(R) Wi-Fi 6 AX200' • Wi-Fi 6 AX200/AX1650* +
PCI\VEN_8086&DEV_2526='Intel(R) Dual Band Wireless-AC 9260' • Wi-Fi 5 (802.11ac) Wireless-AC 9x6x [Thunder Peak] +
PCI\VEN_8086&DEV_24FD='Intel(R) Dual Band Wireless-AC 8265' • Wi-Fi 5 (802.11ac) Wireless-AC 82x5 [Windstorm Peak]
PCI\VEN_8086&DEV_24F3='Intel(R) Dual Band Wireless-AC 8260' • Wi-Fi 5 (802.11ac) Wireless-AC 8260 [Snow Field Peak]
PCI\VEN_8086&DEV_24FB='Intel(R) Dual Band Wireless-AC 3168' • Wi-Fi 5 (802.11ac) Wireless-AC 3168 [Stone Peak]
PCI\VEN_8086&DEV_3165='Intel(R) Dual Band Wireless-AC 3165' • Wi-Fi 5 (802.11ac) Wireless-AC 3165 [Stone Peak 1x1]
PCI\VEN_8086&DEV_095A='Intel(R) Dual Band Wireless-AC 7265' • Wi-Fi 5 (802.11ac Wireless-AC 7265 [Stone Peak 2]
PCI\VEN_8086&DEV_9DF0='Intel(R) Wi-Fi' • Cannon Point-LP PCH CNVi WiFi (300 series) - ?
PCI\VEN_8086&DEV_A370='Intel(R) Wi-Fi' • Cannon Lake PCH CNVi WiFi (300 series) +
PCI\VEN_8086&DEV_31DC='Intel(R) Wi-Fi' • Gemini Lake PCH CNVi WiFi +
PCI\VEN_8086&DEV_34F0='Intel(R) Wi-Fi' • Ice Lake-LP PCH CNVi WiFi +
PCI\VEN_8086&DEV_3DF0='Intel(R) Wi-Fi' • - ?
PCI\VEN_8086&DEV_02F0='Intel(R) Wi-Fi' • Comet Lake PCH-LP CNVi WiFi (400 series) +
PCI\VEN_8086&DEV_06F0='Intel(R) Wi-Fi' • Comet Lake PCH CNVi WiFi (400 series) + (√)
PCI\VEN_8086&DEV_A0F0='Intel(R) Wi-Fi' • AX101NGW ?
PCI\VEN_8086&DEV_43F0='Intel(R) Wi-Fi' • Tiger Lake PCH CNVi WiFi (500 series)
PCI\VEN_8086&DEV_4DF0='Intel(R) Wi-Fi' • Jasper Lake PCH CNVi WiFi
PCI\VEN_8086&DEV_51F0='Intel(R) Wi-Fi' • Alder Lake-P PCH CNVi WiFi + !!! (√)
PCI\VEN_8086&DEV_7AF0='Intel(R) Wi-Fi' • Alder Lake-S PCH CNVi WiFi (600 series)
PCI\VEN_8086&DEV_54F0='Intel(R) Wi-Fi' • Alder Lake-N PCH CNVi WiFi
PCI\VEN_8086&DEV_7A70='Intel(R) Wi-Fi' • Raptor Lake PCH CNVi WiFi (700 series)
PCI\VEN_8086&DEV_51F1='Intel(R) Wi-Fi' • Raptor Lake PCH CNVi WiFi
PCI\VEN_8086&DEV_7E40='Intel(R) Wi-Fi' • Meteor Lake PCH CNVi WiFi
PCI\VEN_8086&DEV_7F70='Intel(R) Wi-Fi' • Arrow Lake-S PCH CNVi WiFi (800 series)
PCI\VEN_8086&DEV_E340='Intel(R) Wi-Fi' • Panther Lake PCH CNVi WiFi (Core Ultra 3 series)
PCI\VEN_8086&DEV_E440='Intel(R) Wi-Fi' • Panther Lake PCH CNVi WiFi (Core Ultra 3 series) • BE211 [8086:0114]
<NVM_METADATA>
<Devices>
<Device name="GALE2" device_id="0x272B" /> or
<Device name="GALE2" crf_id="0x0f" rf_type="0x0F08" cdb="0x01"/>
</Devices>
<Macs>
<MAC name="TYPHOON" mac_type="0x0042" xnj="0"/>
</Macs>
</NVM_METADATA>
PCI ID: 8086:2725 [Typhoon Peak] Wi-Fi 6E (802.11ax) (AX210/AX1675* 2x2)
8086:2725 1a56 1673 Killer AX1675w 160MHz
8086:2725 1a56 1674 Killer Wi-Fi 6E AX1675x 160MHz
8086:2725 8086 0020 Wi-Fi 6 AX210 160MHz
8086:2725 8086 0024 Wi-Fi 6 AX210 160MHz
8086:2725 8086 0090 Wi-Fi 6 AX211 160MHz
8086:2725 8086 00b0 Wi-Fi 6 AX411 160MHz
<NVM_METADATA>
<Devices>
<Device name="STONE_D1" device_id="0x095A" />
<Device name="STONE_D1_DELL" device_id="0x095B" />
<Device name="STONE1" device_id="0x3165" />
<Device name="LIGHTNING1" device_id="0x5501" />
<Device name="LIGHTNING" device_id="0x5502" />
<Device name="SNOWFIELD" device_id="0x24F3" />
<Device name="SNOWFIELD_LENOVO" device_id="0x24F4" />
<Device name="SNOWFIELD1" device_id="0x24F5" />
<Device name="SNOWFIELD1_LENOVO" device_id="0x24F6" />
<Device name="WINDSTORM" device_id="0x24FD" />
<Device name="THUNDER" crf_id="0x01" rf_type="0x0105"
killer_subvednor_id="0x1A56" killer_subsystem_id="0x1550" />
<Device name="JEFFERSON" crf_id="0x03" rf_type="0x0105"
killer_subvednor_id="0x1A56" killer_subsystem_id="0x1551"/>
<Device name="JEFFERSON" crf_id="0x03" rf_type="0x0105"
killer_subvednor_id="0x1A56" killer_subsystem_id="0x1552"/>
<Device name="JEFFERSON1" crf_id="0x06" rf_type="0x0108" />
<Device name="JEFFERSON1D" crf_id="0x0A" rf_type="0x0108" />
<Device name="SUNNY" crf_id="0x0C" rf_type="0x010B" />
<Device name="HARRISON2" crf_id="0x07" rf_type="0x010A"
killer_subvednor_id="0x1A56" killer_subsystem_id="0x1651"/>
<Device name="HARRISON2" crf_id="0x07" rf_type="0x010A"
killer_subvednor_id="0x1A56" killer_subsystem_id="0x1652"/>
<Device name="HARRISON1" crf_id="0x04" rf_type="0x010C" />
<Device name="CYCLONE" crf_id="0x08" rf_type="0x010A"
killer_subvednor_id="0x1A56" killer_subsystem_id="0x1653"/>
<Device name="CYCLONE" crf_id="0x08" rf_type="0x010A"
killer_subvednor_id="0x1A56" killer_subsystem_id="0x1654"/>
<Device name="GARFIELD2" crf_id="0x09" rf_type="0x010D" />
<Device name="GARFIELD2_TC" crf_id="0x09" rf_type="0x0F08" />
<Device name="TYPHOON" crf_id="0x02" rf_type="0x010D" />
<Device name="GARFIELD4" crf_id="0x0b" rf_type="0x010D" cdb="0x01"/>
</Devices>
<Macs>
<MAC name="THUNDER" mac_type="0x0032" />
<MAC name="THUNDER_1" mac_type="0x0032" />
<MAC name="PNJ" mac_type="0x0032" />
<MAC name="QNJ" mac_type="0x0036" />
<MAC name="SNJ" mac_type="0x0042" xnj="1"/>
<MAC name="PULSAR" mac_type="0x0030" />
<MAC name="PULSAR_B" mac_type="0x0031" />
<MAC name="QUASAR_B" mac_type="0x0033" />
<MAC name="QUASAR_V" mac_type="0x0035" />
<MAC name="QUASAR_Z" mac_type="0x0041" />
<MAC name="SUNNY" mac_type="0x0039" />
<MAC name="CYCLONE" mac_type="0x0034" />
<MAC name="TYPHOON" mac_type="0x0042" xnj="0"/>
</Macs>
</NVM_METADATA>
802.11a : 0x0101 (5GHz)
802.11n : 0x0105
802.11ac (Wi-Fi 5) : 0x0108
802.11ax (Wi-Fi 6) : 0x010A, 0x010C, 0x010D
802.11be (Wi-Fi 7) : 0x0F08
|
Specifications
See also: Intel Wi-Fi 6 AX series and Intel Roadmap
|
|
