Radxa ROCK 4SE
From TechInfoDepot
Jump to navigationJump to search
abgn+ac (AC600) | |||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Single Board Computer | |||||||||||||||||||||
![]() | |||||||||||||||||||||
Homepage | Product page | ||||||||||||||||||||
Support | Support page | ||||||||||||||||||||
3rd Party Firmware | |||||||||||||||||||||
dd-wrt | Status Unknown | ||||||||||||||||||||
OpenWrt | Supported | ||||||||||||||||||||
Tomato any flavor | Incompatible | ||||||||||||||||||||
Gargoyle | Status Unknown | ||||||||||||||||||||
Platform | |||||||||||||||||||||
Brand • Model • Rev | Radxa Rock Pi 4SE | ||||||||||||||||||||
FCC ID | none specified | ||||||||||||||||||||
Type | single-board computer | ||||||||||||||||||||
CPU1 ![]() | Rockchip RK3399-T | ||||||||||||||||||||
CPU1 Type | ARM Cortex-A72 | ||||||||||||||||||||
CPU1 Type2 | ARM Cortex-A53 | ||||||||||||||||||||
CPU1 Speed | 1.5 GHz ( 2 cores ) | ||||||||||||||||||||
CPU1 Speed2 | 1.4 GHz ( 4 cores ) | ||||||||||||||||||||
Flash1 Chip | Brand? Model? | ||||||||||||||||||||
Flash1 Size | ? MiB (eMMC/microSD) | ||||||||||||||||||||
RAM1 Size | 4 GiB 4,096 MiB <br />4,294,967,296 B <br />33,554,432 Kib <br />4,194,304 KiB <br />32,768 Mib <br /> (LPDDR4) | ||||||||||||||||||||
RAM1 Chip | Brand? Model? | ||||||||||||||||||||
ETH chip1 | Brand? Model? | ||||||||||||||||||||
Ethernet Port Count | 1-1GbE-LAN | ||||||||||||||||||||
Wired Standard | IEEE 802.3i/3u/3ab | ||||||||||||||||||||
802dot11 OUI: none specified | |||||||||||||||||||||
Stock bootloader | U-Boot | ||||||||||||||||||||
Expansion IF types | microSD, USB 3.0, M.2 M Key (4‑lane PCIe 2.1), HDMI | ||||||||||||||||||||
USB ports | 2 | ||||||||||||||||||||
SD/MMC Slots | 1 | ||||||||||||||||||||
M.2 Slots | 1 | ||||||||||||||||||||
HDMI | 2 | ||||||||||||||||||||
USB Hub Compatible | Untested | ||||||||||||||||||||
Power | 5 VDC, 3 A | ||||||||||||||||||||
Connector type | USB Type‑C | ||||||||||||||||||||
Serial Port (UART) | yes, 3.3V TTL, 1500000 / 8N1 | ||||||||||||||||||||
| |||||||||||||||||||||
| |||||||||||||||||||||
Other | |||||||||||||||||||||
| |||||||||||||||||||||
3rd Party Firmware Support |
OpenWrt • (List | Dev | DLs) | ||||||||||||||||||||
Radio 1 | |||||||||||||||||||||
Radio1 module | AzureWave AW-CM256SM | ||||||||||||||||||||
Radio1 module IF | SDIO/UART | ||||||||||||||||||||
Chip1 | Cypress CYW43455 | ||||||||||||||||||||
Wireless interface OUI | none specified | ||||||||||||||||||||
Antenna Connector Type | U.FL | ||||||||||||||||||||
MIMO status | 1x1:1 | ||||||||||||||||||||
Wireless Standard | IEEE 802.11a/b/g/n/ac | ||||||||||||||||||||
802.11ac | up to 433 Mbps | ||||||||||||||||||||
802.11n | up to 150/150 Mbps | ||||||||||||||||||||
802.11g | up to 54 Mbps | ||||||||||||||||||||
802.11b | up to 11 Mbps | ||||||||||||||||||||
802.11a | up to 54 Mbps | ||||||||||||||||||||
WiFi Operating Frequency | 2.4 or 5 GHz | ||||||||||||||||||||
|
For a list of all currently documented Cypress (Broadcom) chipsets with specifications, see Cypress.
For a list of all currently documented Rockchip SoC's with specifications, see Rockchip.
For a list of all currently documented Radxa devices with specifications, see Radxa.
Overview
Hardware specs
Rockchip RK3399‑T SoC
- Arm® big.LITTLE™ technology (Dual Cortex®‑A72, freqency 1.5Ghz, quad Cortex®‑A53,
frequency 1.0Ghz)
- Arm Mali™ T860MP4 GPU, supporting OpenGL® ES 1.1 / 2.0 / 3.0 / 3.1 / 3.2, Vulkan® 1.0,
OpenCL® 1.1 / 1.2, DirectX® 11.1.
- Dual channel 4GB 64bit LPDDR4
- Dual display via HDMI and MIPI DSI supporting mirror or extend modes
- H.265/VP9 (HEVC) hardware decode (up to 4Kp60)
- H.264 hardware decode (up to 1080p60)
- USB Type‑C™ PD/QC power input
- eMMC/M.2 (M key) connectors
Flashing
![]() | NOTE: During configuration or flashing a device, the only things that should be hooked to the device is the computer and power. |
Flashing OpenWrt
![]() | The development branch can contain experimental code that is under active development and should not be used for production environments. Snapshot images may support additional hardware; however, it is experimental, considered unstable, and sometimes won't compile. |
![]() | Prebuilt snapshot images do not come with any web interface or GUI. You will need to be comfortable using a command line and remote shell to install one yourself → How to install LuCI |
![]() | Devices with Broadcom WiFi chipsets have limited OpenWrt supportability (due to limited FLOSS driver availability for Broadcom chips). Consider this when choosing a device to buy, or when deciding to flash OpenWrt on your device because it is listed as supported. See Broadcom WiFi for details. |
On the OpenWrt ToH (techdata entry)
OpenWrt Target: rockchip
OpenWrt Subtarget: armv8
OpenWrt Package architecture: aarch64_generic
Support started version: unknown
Current supported version: snapshot
Unsupported Functions:
WLAN Hardware
OpenWrt Target: rockchip
OpenWrt Subtarget: armv8
OpenWrt Package architecture: aarch64_generic
Support started version: unknown
Current supported version: snapshot
Unsupported Functions:
WLAN Hardware
Please insert instructions here
