TP-LINK TL-ST1008F v2
From TechInfoDepot
(Redirected from TP-Link TL-ST1008F v2.0)
Jump to navigationJump to search
8-Port 10G Unmanaged Ethernet Switch | |
![]() | |
Homepage | Product page |
---|---|
WikiDevi.wi-cat.ru | TP-LINK TL-ST1008F v2 |
3rd Party Firmware | |
dd-wrt | Status Unknown |
OpenWrt | Supported |
Tomato any flavor | Incompatible |
Gargoyle | Status Unknown |
Platform | |
Brand • Model • Rev | TP-LINK TL-ST1008F v2 |
CPU1 ![]() | Realtek RTL9303 |
CPU1 Type | MIPS 34Kc |
CPU1 Speed | 800 MHz |
Flash1 Chip | Winbond W25Q256JVFQ |
Flash1 Size | 32 MiB33,554,432 B <br />262,144 Kib <br />32,768 KiB <br />256 Mib <br />0.0313 GiB <br /> |
RAM1 Size | 512 MiB536,870,912 B <br />4,194,304 Kib <br />524,288 KiB <br />4,096 Mib <br />0.5 GiB <br /> (DDR3 SDRAM) |
RAM1 Chip | Samsung K4B4G1646E-BYMA |
ETH chip1 | Realtek RTL9303 |
Switch | Realtek RTL9303 |
Ethernet Port Count | 8-10GbE |
Ethernet connector | 8P8C |
Wired Standard | IEEE 802.3i/3u/3ab/3bz/an |
Auto-MDIX | supported |
Jumbo frame | yes |
Switch Class | smart |
Ethernet OUI: none specified | |
Expansion IF types | SFP+ |
SFP ports | 8 |
Stock bootloader | U-Boot |
Power | 12 VDC, 2 A |
Connector type | barrel |
Serial Port (UART) | yes, 3.3, 115200 / 8N1 |
Other | |
| |
Flags: unmanaged, fan, metal case | |
3rd Party Firmware Support |
OpenWrt • (List | Dev | DLs) |
Retail | |
Country of manuf | China |
For a list of all currently documented Realtek chipsets with specifications, see Realtek.
For a list of all currently documented TP-LINK devices with specifications, see TP-LINK.
Links of Interest
Flashing
![]() | NOTE: During configuration or flashing a device, the only things that should be hooked to the device is the computer and power. |
Flashing OpenWrt
![]() | The development branch can contain experimental code that is under active development and should not be used for production environments. Snapshot images may support additional hardware; however, it is experimental, considered unstable, and sometimes won't compile. |
![]() | Prebuilt snapshot images do not come with any web interface or GUI. You will need to be comfortable using a command line and remote shell to install one yourself → How to install LuCI |
On the OpenWrt ToH (techdata entry)
On the github
OpenWrt Target: realtek
OpenWrt Subtarget: rtl930x
OpenWrt Package architecture: mips_24kc
Support started version: unknown
Current supported version: snapshot
On the github
OpenWrt Target: realtek
OpenWrt Subtarget: rtl930x
OpenWrt Package architecture: mips_24kc
Support started version: unknown
Current supported version: snapshot
Please insert instructions here
