Lite-On WN6301L (Toshiba)
bg (G54) | |||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Wireless g Mini PCIe Module | |||||||||||||||
![]() | |||||||||||||||
WikiDevi.wi-cat.ru | Lite-On WN6301L (Toshiba) | ||||||||||||||
Platform | |||||||||||||||
Brand • Model • Rev | Lite-On WN6301L (Toshiba) | ||||||||||||||
Interface | USB 2.0 | ||||||||||||||
Connector | Mini PCIe | ||||||||||||||
ID:0bda:8197 (1 addl. devices) | |||||||||||||||
| |||||||||||||||
FCCID | TX2-RTL8187B | ||||||||||||||
Chip1 | Realtek RTL8187B | ||||||||||||||
Chip2 | Realtek RTL8225 | ||||||||||||||
Wireless Standards | IEEE 802.11b/g | ||||||||||||||
802.11g | up to 54 Mbps | ||||||||||||||
802.11b | up to 11 Mbps | ||||||||||||||
Operating Frequency | 2.4 GHz | ||||||||||||||
Additional chips | |||||||||||||||
Probable Linux driver | |||||||||||||||
Windows driver | |||||||||||||||
Retail | |||||||||||||||
FCC approval date | 06 February 2007 | ||||||||||||||
| |||||||||||||||
|
For a list of all currently documented Realtek chipsets with specifications, see Realtek.
For a list of all currently documented Lite-On devices with specifications, see Lite-On.
- • 54 Mbps - 2.4GHz 802.11g = G54 class
Overview
Toshiba K000065820 (OUI: 70:1A:04, v03, 0bda:8197)
Toshiba V000101870 (OUI: 00:16:44, v01, 0bda:8197)
Gateway 83-5020000008G (OUI: 00:16:44, v01, 0bda:8189)
Output of sudo lsusb -v -d 0bda:8197 here, or here.
