Jump to navigationJump to searchAzureWave
See also: AzureWave Wireless Adapters
Automatically generated tables
Embedded System
2 total devices
| Device | Type | PHY modes | Manuf. | CPU1 | FLA1 | RAM1 | Radio1 | Radio2 | Switch | Ether. | Expan. | Ports | FCC date |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AzureWave AW-CU282 FCC ID: TLZ-CU282 |
module | bgn N150 |
Marvell 88MC200 200 MHz 1 cores |
int. 1 MiB1,048,576 B <br />8,192 Kib <br />1,024 KiB <br />8 Mib <br />9.765625e-4 GiB <br /> |
int. 0.5 MiB524,288 B <br />4,096 Kib <br />512 KiB <br />4 Mib <br />4.882812e-4 GiB <br /> |
Marvell 88W8782 1x1:1, bgn Ant. conn: none specified |
2013-05-02 | ||||||
| AzureWave AW-CU288 FCC ID: TLZ-CU288 |
module | bgn N150 |
Marvell 88MC200 200 MHz 1 cores |
int. 1 MiB1,048,576 B <br />8,192 Kib <br />1,024 KiB <br />8 Mib <br />9.765625e-4 GiB <br /> |
int. 0.5 MiB524,288 B <br />4,096 Kib <br />512 KiB <br />4 Mib <br />4.882812e-4 GiB <br /> |
Marvell 88W8801 1x1:1, bgn Ant. conn: none specified |
2014-08-12 |
Manuf Embedded Systems
1 total devices
| Device | Type | PHY modes | Manuf. | CPU1 | FLA1 | RAM1 | Radio1 | Radio2 | Switch | Ether. | Expan. | Ports | FCC date |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| D-Link DWR-730 rev A1 FCC ID: KA2WR730A1 Wi-Fi Certified |
mobile hotspot | bg G54 |
AzureWave AW-4020 CoO:
|
ST-Ericsson DB5700 |
Samsung |
unk. ?x?:?, bg Ant. conn: none specified Is a module AzureWave AW-? |
microSD | 2012-02-15 |
Network Adapters
115 total devices
| Device | Interface | PHY modes |
Manuf. | Chip1 | Chip2 | MIMO | Addl. info |
FCC date |
|---|---|---|---|---|---|---|---|---|
| AzureWave AW-AB116H FCC ID: PPD-AR5B22 has external images |
Mini PCIe Half Mini Card [half], Mini PCIe |
abgn AN600 168c:0034 |
Atheros AR9462 |
2x2:2 ath9k |
OUI: 6C:71:D9 Ant. conn: U.FL Flags: Bluetooth 4.0 |
2012-02-03 | ||
| AzureWave AW-AE750 FCC ID: PPD-AR5BXB6-M |
Mini PCIe --, Mini PCIe |
abg AG108 |
Atheros AR5424 |
ath5k, madwifi |
OUI: 00:15:AF Ant. conn: |
2005-07-14 | ||
| AzureWave AW-AH397 | SDIO 3.0 module [SiP], SD (solder down) |
abgn AN300 |
AzureWave |
Marvell 88W8797 |
1x1:1 mwifiex |
Ant. conn: Flags: Bluetooth 4.0, FM radio |
||
| AzureWave AW-CB160H FCC ID: QDS-BRCM1082 has external images |
Mini PCIe [half], Mini PCIe |
abgn+ac AC1750 14e4:43a0 |
CoO:
|
Broadcom BCM4360 |
3x3:3 wl 6 |
OUI: 54:27:1E, 40:E2:30 Ant. conn: MHF4 Flags: Bluetooth 4.0, short-term conf template expired |
2014-06-16 | |
| AzureWave AW-CB161H FCC ID: TX2-RTL8821AE, TLZ-CB161H |
Mini PCIe [half], Mini PCIe |
abgn+ac AC600 10ec:8821 |
CoO:
|
Realtek RTL8821AE |
1x1:1 rtl8821ae, rtlwifi_new (WIP) |
OUI: 54:27:1E Ant. conn: U.FL Flags: Bluetooth |
2013-07-10 | |
| AzureWave AW-CB162NF FCC ID: TLZ-CB162NF, QDS-BRCM1076 |
M.2 --, M.2 |
abgn+ac AC1200 14e4:43b1 |
CoO:
|
Broadcom BCM4352 |
2x2:2 wl 6 |
OUI: 24:0A:64 Ant. conn: MHF4 Flags: Bluetooth |
||
| AzureWave AW-CB178NF FCC ID: TLZ-CB178NF |
M.2 2230, M.2 |
abgn+ac AC1200 |
AzureWave |
Marvell 88W8897 |
2x2:2 mwifiex |
OUI: 54:27:1E Ant. conn: Flags: Bluetooth 4.0, DFS |
2014-10-13 | |
| AzureWave AW-CB209NF FCC ID: TX2-RTL8821AE, TLZ-CB209NF |
M.2 --, M.2 |
abgn+ac AC600 10ec:8821 |
Realtek RTL8821AE |
1x1:1 rtl8821ae, rtlwifi_new (WIP) |
Ant. conn: MHF4 | 2013-07-10 | ||
| AzureWave AW-CB210NF FCC ID: TLZ-CB210NF, QDS-BRCM1085 |
M.2 2230, M.2 |
abgn+ac AC1200 14e4:43ec |
CoO:
|
Broadcom BCM4356 |
2x2:2 brcmfmac |
Ant. conn: U.FL Flags: Bluetooth 4.1 |
||
| AzureWave AW-CB231NF FCC ID: PPD-QCNFA435 |
M.2 1630, M.2 |
abgn+ac AC600 168c:0042 |
Qualcomm Atheros QCA9377 |
1x1:1 ath10k |
Ant. conn: MHF4 Flags: Bluetooth |
2014-12-26 | ||
| AzureWave AW-CB295NF FCC ID: TX2-RTL8822BE |
USB 2.0 2230, M.2 1.1 (Key A/E) |
abgn+ac AC1200 10ec:b822 |
AzureWave CoO:
|
Realtek RTL8822BE |
2x2:2 rtw88, rtlwifi_new |
Ant. conn: MHF4 Flags: Wave2, VHT80, MU-MIMO, Bluetooth 4.2 |
2016-08-29 | |
| AzureWave AW-CB375NF FCC ID: TX2-RTL8822CE |
USB 2.0 2230 [Key A+E], M.2 |
abgn+ac AC1200 |
Realtek RTL8822CE |
2x2:2 rtw88, rtlwifi_new |
OUI: 70:66:55 Ant. conn: MHF4 Flags: Bluetooth 5.0, Wave2, MU-MIMO |
2018-11-02 | ||
| AzureWave AW-CE123H FCC ID: QDS-BRCM1068 has external images |
Mini PCIe [half], Mini PCIe |
abgn+ac AC1200 14e4:43b1 |
AzureWave CoO:
|
Broadcom BCM4352 |
2x2:2 wl 6 |
OUI: 24:0A:64, 6C:71:D9 Ant. conn: U.FL Flags: Bluetooth 4.0 |
2012-10-16 | |
| AzureWave AW-CM256SM FCC ID: 2A3PA-ROCK4C, 2A3PA-RADXA-CM3 has external images |
SDIO 3.0 [module], LGA (SD) |
abgn+ac AC600 02d0:a9bf |
AzureWave CoO:
|
Cypress CYW43455 |
1x1:1 unknown |
OUI: 00:90:4C Ant. conn: U.FL |
||
| AzureWave AW-CM276NF FCC ID: UAY-W8997-M1216 has internal images |
M.2 2.0 1216, SD (solder down) |
abgn+ac AC1200 |
AzureWave |
Marvell 88W8997 |
2x2:2 mwifiex |
Ant. conn: MHF4 Flags: Wave2, MU-MIMO, Bluetooth 4.2, DFS (slave) |
2017-01-25 | |
| AzureWave AW-CM308NF FCC ID: TLZ-CM308NF |
USB 2.0 1216, M.2 1.1 |
abgn+ac AC1200 10ec:b822 |
AzureWave CoO:
|
Realtek RTL8822BE |
2x2:2 rtw88, rtlwifi_new |
Ant. conn: MHF4 Flags: Wave2, DFS, MU-MIMO, Bluetooth 4.2, short-term conf template expired |
2017-08-10 | |
| AzureWave AW-CM389NF FCC ID: TLZ-CM389NF |
M.2 2.0 1216 [module], M.2 (LGA SD) |
abgn+ac AC1200 |
AzureWave CoO:
|
Marvell 88W8897 |
2x2:2 mwifiex |
Ant. conn: MHF4 Flags: Bluetooth 4.2 LE, DFS, Datasheet |
2014-07-09 | |
| AzureWave AW-CM390SM FCC ID: TLZ-CM390SM |
SDIO 3.0 module [12x12], SD (solder down) |
abgn+ac AC600 1a3b:2390 |
AzureWave |
Cypress CYW43455 |
1x1:1 unknown |
Ant. conn: MHF4 Flags: Bluetooth 5.0, DFS (slave) |
2020-06-15 | |
| AzureWave AW-EB600NF FCC ID: RAS-MT7925B22M |
M.2 2.1 2230, M.2 (Key E) |
abgn+ac+ax+be BE3600 14c3:7925 |
CoO:
|
MediaTek MT7925A |
2x2:2 |
Ant. conn: MHF4 Flags: WPA3, Wi-Fi Direct, WMM, Wi-Fi Agile Multiband, Wi-Fi 7, Bluetooth 5.4 LE |
2023-09-28 | |
| AzureWave AW-GA800 FCC ID: TLZ-GA800 Wi-Fi Certified |
USB 2.0 --, (non-standard connector) |
bg G54 |
Realtek RTL8187L |
Realtek RTL8225 |
rtl8187 |
Ant. conn: | 2005-09-14 | |
| AzureWave AW-GA800BT FCC ID: TLZ-800BT Wi-Fi Certified has internal images |
USB 2.0 --, (non-standard connector) |
bg G54 |
Realtek RTL8187L |
Realtek RTL8225 |
rtl8187 |
OUI: 00:15:AF Ant. conn: RP-SMA |
2006-05-05 | |
| AzureWave AW-GA821 FCC ID: TLZ-GA821 |
PCIe --, (non-standard connector) |
bg G54 |
CoO:
|
Atheros AR2425 |
ath5k, madwifi |
Ant. conn: RP-SMA | 2006-11-09 | |
| AzureWave AW-GA826 FCC ID: TLZ-GA826 Wi-Fi Certified |
USB 2.0 --, (non-standard connector) |
bg G54 |
ZyDAS ZD1211B |
Ubec UW2453 |
zd1211rw |
Ant. conn: RP-SMA | 2007-08-24 | |
| AzureWave AW-GB038H FCC ID: QDS-BRCM1044 has external images |
Mini PCIe [half], Mini PCIe |
bg G54 14e4:4315 |
Broadcom BCM4312 |
b43 |
OUI: 1C:4B:D6 Ant. conn: U.FL Flags: Bluetooth |
2009-04-06 | ||
| AzureWave AW-GD200 FCC ID: TLZ-GD200 |
Mini PCI --, Mini PCI |
bg G54 |
Marvell 88W8510 |
Marvell 88W8010 |
none |
Ant. conn: U.FL | 2006-01-04 | |
| AzureWave AW-GE112H FCC ID: PPD-AR5B95 has external images |
Mini PCIe [half], Mini PCIe |
bg G54 168c:002c |
Atheros AR2427 |
ath9k |
OUI: 00:25:D3, 48:5D:60 Ant. conn: U.FL |
2008-12-12 | ||
| AzureWave AW-GE703 | Mini PCIe --, Mini PCIe |
bg G54 |
Realtek RTL8187SE |
rtl8187se, rtl818x_pci |
Ant. conn: U.FL | |||
| AzureWave AW-GE740 FCC ID: PPD-AR5BXB61 |
Mini PCIe --, Mini PCIe |
bg G54 |
Atheros AR2423 |
ath5k, madwifi |
OUI: 00:15:AF Ant. conn: |
2005-10-26 | ||
| AzureWave AW-GE780 FCC ID: PPD-AR5BXB63, JCK-M912 has external images |
Mini PCIe --, Mini PCIe |
bg G54 168c:001c |
CoO:
|
Atheros AR2425 |
ath5k, madwifi |
OUI: 00:15:AF, 00:22:43 Ant. conn: U.FL |
2006-08-07 | |
| AzureWave AW-GE870 FCC ID: TLZ-GE870 Wi-Fi Certified has external images |
PCIe --, PCIe |
bg G54 |
CoO:
|
Atheros AR2425 |
ath5k, madwifi |
Ant. conn: RP-SMA | 2007-01-24 | |
| AzureWave AW-GH321 has external images |
SDIO --, SDIO (module) |
bg G54 |
AzureWave CoO:
|
Marvell 88W8686 |
libertas |
Ant. conn: | ||
| AzureWave AW-GH381 | SDIO --, SDIO (module) |
bg G54 |
AzureWave CoO:
|
Marvell 88W8688 |
Ant. conn: Flags: Bluetooth |
|||
| AzureWave AW-GM100 FCC ID: TLZ-GM100 |
Mini PCI --, Mini PCI |
bg G54 |
Marvell 88W8335 |
Marvell 88W8010 |
mrv8k (OoK, non-functional) |
OUI: 00:15:AF Ant. conn: U.FL |
2005-09-19 | |
| AzureWave AW-GM120 FCC ID: TLZ-GM120 |
Mini PCI --, Mini PCI |
bg G54 |
Atheros AR2413 |
ath5k, madwifi |
Ant. conn: U.FL | 2005-11-23 | ||
| AzureWave AW-GM320 FCC ID: TLZ-GM320 |
Mini PCIe --, Mini PCIe |
bg G54 |
CoO:
|
Marvell 88W8686 |
libertas |
Ant. conn: U.FL | 2008-10-20 | |
| AzureWave AW-GU700 FCC ID: TLZ-GU700 |
USB 2.0 --, Mini PCIe |
bg G54 0bda:8187 |
CoO:
|
Realtek RTL8187L |
Realtek RTL8225 |
rtl8187 |
OUI: 00:15:AF, 00:22:43 Ant. conn: U.FL |
2006-05-19 |
| AzureWave AW-GU701 FCC ID: TX2-RTL8187B |
USB 2.0 --, Mini PCIe |
bg G54 |
Realtek RTL8187B |
Realtek RTL8225 |
rtl8187 |
OUI: 00:15:AF Ant. conn: U.FL |
2007-02-06 | |
| AzureWave AW-GU702 FCC ID: TX2-RTL8187B |
USB 2.0 --, Mini PCIe |
bg G54 0bda:8189 |
AzureWave CoO:
|
Realtek RTL8187B |
Realtek RTL8225 |
rtl8187 |
OUI: 00:22:43 Ant. conn: U.FL |
2007-02-06 |
| AzureWave AW-HM482 FCC ID: TLZ-HM482 |
SDIO 3.0 2230, SD (LGA) |
ah AH15 1a3b:2482 |
AzureWave CoO:
|
Newracom NRC7292 |
RFMD FM6901 |
1x1:1 unknown |
Ant. conn: Flags: HaLow, MCU SoC |
2021-09-28 |
| AzureWave AW-NA830 FCC ID: TLZ-NA830 |
USB 2.0 --, (non-standard connector) |
bgn N150 |
CoO:
|
Ralink RT2770 |
Ralink RT2720 |
1x2:2 rt2800usb, rt2870sta |
Ant. conn: RP-SMA | 2007-07-27 |
| AzureWave AW-NB037H FCC ID: PPD-AR5B195 has external images |
Mini PCIe [half], Mini PCIe |
bgn N150 168c:002b |
Atheros AR9285 |
1x1:1 ath9k |
OUI: 00:08:CA, 1C:4B:D6, 74:2F:68, E0:B9:A5 Ant. conn: U.FL Flags: Bluetooth |
2009-10-09 | ||
| AzureWave AW-NB041H FCC ID: VQF-RT3090BC4 |
Mini PCIe [half], Mini PCIe |
bgn N150 |
Ralink RT3090 |
1x1:1 rt2800pci, rt2860sta |
OUI: 48:5D:60 Ant. conn: U.FL Flags: Bluetooth |
2009-12-11 | ||
| AzureWave AW-NB047H FCC ID: QDS-BRCM1051 |
Mini PCIe [half], Mini PCIe |
bgn N150 |
Broadcom BCM4313 |
1x1:1 brcmsmac, wl |
OUI: 48:5D:60 Ant. conn: U.FL Flags: Bluetooth |
2009-11-10 | ||
| AzureWave AW-NB048H FCC ID: PPD-AR5B195 |
Mini PCIe [half], Mini PCIe |
bgn N150 168c:002b |
Atheros AR9285L |
1x1:1 ath9k |
OUI: 00:08:CA, 1C:4B:D6 Ant. conn: U.FL Flags: Bluetooth |
2009-10-09 | ||
| AzureWave AW-NB057H FCC ID: TX2RTL8188CEBT, JCK-S2005, JCK-M1005 |
Mini PCIe [half], Mini PCIe |
bgn N150 10ec:8176 |
Realtek RTL8188CE |
1x1:1 rtl8192ce, Realtek's vendor driver |
OUI: 48:5D:60 Ant. conn: U.FL Flags: Bluetooth |
2010-03-23 | ||
| AzureWave AW-NB078H FCC ID: TX2RTL8188CEB8 |
Mini PCIe [half], Mini PCIe |
bgn N150 |
Realtek RTL8188CE |
1x1:1 rtl8192ce, Realtek's vendor driver |
OUI: E0:B9:A5 Ant. conn: U.FL Flags: Bluetooth |
2010-10-14 | ||
| AzureWave AW-NB086 FCC ID: TLZ-NB086 has external images |
PCIe --, (non-standard connector) |
bgn N150 168c:0032 |
AzureWave CoO:
|
Atheros AR9485 |
1x1:1 ath9k |
OUI: 00:08:CA, 74:2F:68, E0:B9:A5 Ant. conn: MHF4 Flags: Bluetooth |
2011-08-23 | |
| AzureWave AW-NB087H FCC ID: VQF-RT3290 has external images |
Mini PCIe [half], Mini PCIe |
bgn N150 |
Ralink RT3290 |
1x1:1 rt2800pci, rt3290sta |
Ant. conn: U.FL Flags: Bluetooth |
2011-04-28 | ||
| AzureWave AW-NB097H FCC ID: PPD-AR5B225 |
Mini PCIe [half], Mini PCIe |
bgn N150 168c |
Atheros AR9485 |
1x1:1 ath9k |
OUI: 00:08:CA Ant. conn: U.FL Flags: Bluetooth |
2011-02-17 | ||
| AzureWave AW-NB099H FCC ID: VOB-NB099HA |
module --, module |
abgn AN300 |
Broadcom BCM4330 |
1x1:1 brcmfmac |
Ant. conn: U.FL Flags: Bluetooth |
2012-01-12 | ||
| AzureWave AW-NB100H FCC ID: PPD-AR5B225 |
Mini PCIe [half], Mini PCIe |
bgn N150 168c:0037 |
Atheros AR9485 |
1x1:1 ath9k |
OUI: 94:DB:C9 Ant. conn: U.FL Flags: Bluetooth |
2011-02-17 | ||
| AzureWave AW-NB110H FCC ID: PPD-AR5B22 |
Mini PCIe [half], Mini PCIe |
abgn AN600 |
AzureWave |
Atheros AR9462 |
2x2:2 ath9k |
OUI: 6C:71:D9 Ant. conn: U.FL Flags: Bluetooth 4.0 |
2012-02-03 | |
| AzureWave AW-NB111H FCC ID: QDS-BRCM1058, MSQ-BRCM1058 has external images |
Mini PCIe [half], Mini PCIe |
abgn AN600 14e4:4359 |
Broadcom BCM43228 |
2x2:2 wl |
OUI: DC:85:DE Ant. conn: U.FL Flags: DFS, Bluetooth |
2011-06-30 | ||
| AzureWave AW-NB114H FCC ID: TX2-RTL8723AE has external images |
Mini PCIe [half], Mini PCIe |
bgn N150 10ec:8723 |
AzureWave CoO:
|
Realtek RTL8723AE |
1x1:1 rtl8723ae, rtlwifi_new (WIP) |
OUI: 6C:71:D9, 24:0A:64, 28:C2:DD Ant. conn: U.FL Flags: Bluetooth 4.0 |
2011-12-06 | |
| AzureWave AW-NB126H FCC ID: PPD-AR5B225 |
Mini PCIe [half], Mini PCIe |
bgn N150 |
Atheros AR9485 |
1x1:1 ath9k |
Ant. conn: U.FL Flags: Bluetooth |
2012-12-31 | ||
| AzureWave AW-NB159H FCC ID: TLZ-NB159H, TX2-RTL8723BE |
Mini PCIe 2.0 HMC [half], Mini PCIe |
bgn N150 10ec:b723 |
AzureWave |
Realtek RTL8723BE |
1x1:1 rtl8723be, rtlwifi_new (WIP) |
Ant. conn: U.FL Flags: Bluetooth 4.0 |
2013-05-08 | |
| AzureWave AW-NB165NF FCC ID: TLZ-NB165NF, TX2-RTL8723BE |
M.2 2.0 2230, M.2 |
bgn N150 10ec:b723 |
Realtek RTL8723BE |
1x1:1 rtl8723be, rtlwifi_new (WIP) |
Ant. conn: MHF4 Flags: Bluetooth 4.0 |
2013-05-08 | ||
| AzureWave AW-NB177NF FCC ID: TLZ-NB177NF, TX2-RTL8723BS |
SDIO 1216, M.2 |
bgn N150 |
Realtek RTL8723BS |
1x1:1 unknown, fix |
Ant. conn: MHF4 Flags: Bluetooth 4.0 |
2014-05-14 | ||
| AzureWave AW-NB182NF FCC ID: PPD-QCNFA335 |
M.2 1630, M.2 |
bgn N150 168c:0036 |
Qualcomm Atheros QCA9565 |
1x1:1 ath9k |
Ant. conn: MHF4 Flags: Bluetooth |
2013-10-23 | ||
| AzureWave AW-NB290H FCC ID: QDS-BRCM1048 has external images |
Mini PCIe [half], Mini PCIe |
bgn N300 |
Broadcom BCM43225 |
2x2:2 brcmsmac, b43, wl |
OUI: 74:2F:68 Ant. conn: U.FL Flags: Bluetooth 3.0 |
2009-05-14 | ||
| AzureWave AW-NC100 | PCMCIA (32-bit) | bgn N300 |
unk. |
2x2:2 unknown |
Ant. conn: | |||
| AzureWave AW-NE104H FCC ID: TX2-RTL8191SE |
Mini PCIe [half], Mini PCIe |
bgn N150 10ec:8171 |
Realtek RTL8191SE |
1x2:2 rtl8192se |
Ant. conn: U.FL | 2009-01-22 | ||
| AzureWave AW-NE104HS FCC ID: TX2-RTL8191SE |
Mini PCIe [half], Mini PCIe |
bgn N150 10ec:8172 |
Realtek RTL8191SE |
1x2:2 rtl8192se |
OUI: 1C:4B:D6, 74:F0:6D Ant. conn: U.FL |
2009-01-22 | ||
| AzureWave AW-NE106 FCC ID: TLZ-NE106 |
PCIe --, (non-standard connector) |
bgn N150 |
Atheros AR9285 |
1x1:1 ath9k |
Ant. conn: U.FL | 2009-07-09 | ||
| AzureWave AW-NE107H FCC ID: TX2-RTL8191SE |
Mini PCIe [half], Mini PCIe |
bgn N150 |
Realtek RTL8191SE |
1x2:2 rtl8192se |
OUI: 00:25:D3 Ant. conn: U.FL |
2009-01-22 | ||
| AzureWave AW-NE121H FCC ID: PPD-AR5B97 |
Mini PCIe [half], Mini PCIe |
bgn N300 |
AzureWave |
Atheros AR9287 |
2x2:2 ath9k |
OUI: 24:0A:64 Ant. conn: U.FL |
2009-08-14 | |
| AzureWave AW-NE139H FCC ID: TX2-RTL8188CE |
Mini PCIe [half], Mini PCIe |
bgn N150 10ec:8176 |
Realtek RTL8188CE |
1x1:1 rtl8192ce, Realtek's vendor driver |
OUI: E0:B9:A5 Ant. conn: U.FL |
2010-02-10 | ||
| AzureWave AW-NE155H FCC ID: VQF-RT5390 has external images |
Mini PCIe [half], Mini PCIe |
bgn N150 |
Ralink RT5390 |
1x1:1 rt2800pci, rt2860sta |
OUI: 74:2F:68 Ant. conn: U.FL |
2010-07-21 | ||
| AzureWave AW-NE186H FCC ID: PPD-AR5B125 has external images |
Mini PCIe [half], Mini PCIe |
bgn N150 168c:0032 |
AzureWave |
Atheros AR9485 |
1x1:1 ath9k |
OUI: DC:85:DE, 24:0A:64 Ant. conn: |
2011-03-08 | |
| AzureWave AW-NE762H FCC ID: VQF-RT3090-1T1R |
Mini PCIe [half], Mini PCIe |
bgn N150 |
Ralink RT3090 |
1x1:1 rt2800pci, rt2860sta |
OUI: 74:2F:68 Ant. conn: U.FL |
2008-12-10 | ||
| AzureWave AW-NE766 FCC ID: VQF-RT2700E |
Mini PCIe --, Mini PCIe |
bgn N150 1814:0781 |
CoO:
|
Ralink RT2790 |
Ralink RT2720 |
1x2:2 rt2800pci, rt2860sta |
OUI: 00:15:AF Ant. conn: U.FL |
2007-11-12 |
| AzureWave AW-NE768 FCC ID: VQF-RT3091 |
Mini PCIe [half], Mini PCIe |
bgn N150 |
Ralink RT3091 |
1x2:2 rt2800pci, rt2860sta |
Ant. conn: U.FL | 2008-12-04 | ||
| AzureWave AW-NE769 FCC ID: VQF-RT2700E has external images |
PCIe --, PCIe |
bgn N150 |
Ralink RT2790 |
Ralink RT2720 |
1x2:2 rt2800pci, rt2860sta |
OUI: 00:22:43, 00:25:D3 Ant. conn: RP-SMA |
2007-11-12 | |
| AzureWave AW-NE770 FCC ID: PPD-AR5BXB72 |
Mini PCIe --, Mini PCIe |
abgn N300 168c:0024 |
CoO:
|
Atheros AR5418 |
Atheros AR5133 |
2x3:2 ath9k |
OUI: 00:15:AF Ant. conn: U.FL |
2006-06-22 |
| AzureWave AW-NE771 FCC ID: PPD-AR5B91 |
Mini PCIe --, Mini PCIe |
bgn N150 168c:002a |
Atheros AR9281 |
1x2:2 ath9k |
OUI: 00:22:43 Ant. conn: U.FL |
2008-02-24 | ||
| AzureWave AW-NE771H FCC ID: PPD-AR5B91 |
Mini PCIe [half], Mini PCIe |
bgn N150 168c:002a |
Atheros AR9281 |
1x2:2 ath9k |
Ant. conn: U.FL | 2008-02-24 | ||
| AzureWave AW-NE772 FCC ID: PPD-AR5BXB92 |
Mini PCIe --, Mini PCIe |
abgn N300 168c:002a |
CoO:
|
Atheros AR9280 |
2x2:2 ath9k |
OUI: 00:22:43 Ant. conn: U.FL |
2008-03-17 | |
| AzureWave AW-NE773 FCC ID: PPD-AR5BHB92 |
Mini PCIe [half], Mini PCIe |
abgn AN600 168c:002a |
Atheros AR9280 |
2x2:2 ath9k |
OUI: 00:25:D3, 48:5D:60 Ant. conn: U.FL |
2008-03-20 | ||
| AzureWave AW-NE785 FCC ID: PPD-AR5B95 |
Mini PCIe --, Mini PCIe |
bgn N150 168c:002b |
Atheros AR9285 |
1x1:1 ath9k |
OUI: 00:22:43, 00:25:D3 Ant. conn: U.FL |
2008-12-12 | ||
| AzureWave AW-NE785H FCC ID: PPD-AR5B95 |
Mini PCIe [half], Mini PCIe |
bgn N150 168c:002b |
Atheros AR9285 |
1x1:1 ath9k |
OUI: 00:22:43, 00:25:D3, 1C:4B:D6, 48:5D:60, E0:B9:A5 Ant. conn: U.FL |
2008-12-12 | ||
| AzureWave AW-NH387 | SDIO --, SDIO (module) |
bgn N150 |
AzureWave CoO:
|
Marvell 88W8787 |
1x1:1 mwifiex |
Ant. conn: U.FL Flags: Bluetooth |
||
| AzureWave AW-NH660 | module (SiP) | abgn AN300 |
Broadcom BCM4330 |
1x1:1 brcmfmac |
Ant. conn: | |||
| AzureWave AW-NH930 FCC ID: 6100A-NH930 |
SDIO --, (non-standard connector) |
abgn AN300 |
Broadcom BCM4329 |
1x1:1 brcmfmac |
Ant. conn: U.FL Flags: FM radio, Bluetooth 3.0 |
2011-05-24 | ||
| AzureWave AW-NH931 FCC ID: TLZ-NH931 has internal images has external images |
Mini PCIe 2.0 [half], SDIO |
bgn N150 |
CoO:
|
Broadcom BCM4329 |
1x1:1 brcmfmac |
OUI: 74:2F:68 Ant. conn: U.FL Flags: Bluetooth |
2011-02-17 | |
| AzureWave AW-NM191NF FCC ID: TLZ-NM191NF |
SDIO module [solder down], SD (solder down) |
bgn N150 |
Marvell 88W8801 |
1x1:1 mwifiex |
Ant. conn: Flags: HT20, short-term conf template expired |
2019-07-11 | ||
| AzureWave AW-NM230NF FCC ID: TLZ-NM230NF |
M.2 1216, M.2 |
bgn N150 |
Broadcom BCM43438 |
1x1:1 unknown, fix |
Ant. conn: MHF4 Flags: Bluetooth 4.1 LE |
2015-08-10 | ||
| AzureWave AW-NM288SM | SDIO 2.0 module [12x12], SD (solder down) |
bgn N150 |
Cypress CYW43362 |
1x1:1 unknown |
Ant. conn: U.FL | 2016-04-01 (no FCC) | ||
| AzureWave AW-NM313S FCC ID: IXMUGNAS-P3, TLZ-NM313S has external images |
SDIO 2.0 module, SD (solder down) |
bgn N150 |
AzureWave CoO:
|
Marvell 88W8786 |
1x1:1 mwifiex |
Ant. conn: | 2011-07-29 | |
| AzureWave AW-NM333 FCC ID: TLZ-NM333 |
module (SiP) | bgn N150 |
Marvell 88W8801 |
1x1:1 mwifiex |
Ant. conn: Flags: short-term conf template expired |
2018-05-14 | ||
| AzureWave AW-NM387 FCC ID: TLZ-NM387 |
SDIO --, SDIO (module) |
bgn N150 |
Marvell 88W8787 |
1x1:1 mwifiex |
Ant. conn: U.FL Flags: Bluetooth |
2011-02-17 | ||
| AzureWave AW-NM388 FCC ID: TLZ-NM388 |
SDIO --, SDIO (module) |
bgn N150 |
Marvell 88W8787 |
1x1:1 mwifiex |
Ant. conn: U.FL Flags: Bluetooth |
2012-02-13 | ||
| AzureWave AW-NM775 | Mini PCI --, Mini PCI |
bgn N |
unk. |
unknown |
Ant. conn: U.FL | |||
| AzureWave AW-NU103 FCC ID: TLZ-NU103 |
USB 2.0 --, (non-standard connector) |
bgn N150 |
Realtek RTL8188SU |
1x1:1 r8712u, rtl8192su |
Ant. conn: U.FL | 2009-07-02 | ||
| AzureWave AW-NU109H FCC ID: KA2AWNU109HA1 |
USB 2.0 [half], Mini PCIe |
bgn N150 0a5c:bd16 |
AzureWave |
Broadcom BCM4319 |
1x1:1 none |
OUI: 74:F0:6D Ant. conn: U.FL |
2010-08-27 | |
| AzureWave AW-NU137 FCC ID: TLZ-NU137 |
USB 2.0 --, (non-standard connector) |
bgn N150 13d3:3327 |
Atheros AR9271 |
1x1:1 ath9k htc |
Ant. conn: U.FL | 2010-06-18 | ||
| AzureWave AW-NU138 FCC ID: TLZ-NU138 Wi-Fi Certified |
USB 2.0 micro dongle, Male A |
bgn N150 |
Atheros AR9271 |
1x1:1 ath9k htc |
OUI: 74:2F:68 Ant. conn: |
2010-11-15 | ||
| AzureWave AW-NU148 FCC ID: PPD-AR5BUB173 |
USB 2.0 module, (non-standard connector) |
bgn N150 0cf3:9271 |
Atheros AR9271 |
1x1:1 ath9k htc |
OUI: 00:19:9D Ant. conn: U.FL |
2010-10-14 | ||
| AzureWave AW-NU150 FCC ID: TLZ-NU150 |
USB 2.0 micro dongle, Male A |
bgn N150 |
Atheros AR9271 |
1x1:1 ath9k htc |
OUI: 74:2F:68 Ant. conn: |
2010-12-13 | ||
| AzureWave AW-NU153H FCC ID: TLZ-NU153H |
USB 2.0 [half], Mini PCIe |
bgn N150 |
Atheros AR9271 |
1x1:1 ath9k htc |
Ant. conn: U.FL | 2010-11-24 | ||
| AzureWave AW-NU168H FCC ID: VQF-RT5390 has external images |
USB 2.0 [half], Mini PCIe |
bgn N150 148f:5370 |
Ralink RT5370 |
1x1:1 rt2800usb, rt5370sta |
Ant. conn: U.FL | |||
| AzureWave AW-NU182H FCC ID: TLZ-NU182H |
USB 2.0 [half], Mini PCIe |
bgn N300 |
Ralink RT5372 |
2x2:2 rt2800usb, rt5370sta |
OUI: 74:2F:68 Ant. conn: U.FL |
2012-03-05 | ||
| AzureWave AW-NU221 Wi-Fi Certified |
USB 2.0 dongle, Male A |
bgn N300 13d3:3310 |
Ralink RT2870 |
Ralink RT2820 |
2x3:2 rt2800usb, rt2870sta |
OUI: 00:08:CA Ant. conn: |
2007-08-01 (no FCC) | |
| AzureWave AW-NU222 | USB 2.0 --, (non-standard connector) |
bgn N150 13d3:3247 |
CoO:
|
Ralink RT2770 |
Ralink RT2720 |
1x2:2 rt2800usb, rt2870sta |
OUI: 00:22:43 Ant. conn: |
2007-11-01 (no FCC) |
| AzureWave AW-NU224 FCC ID: TLZ-NU224 Wi-Fi Certified |
USB 2.0 internal wireless module, Female Mini-B |
bgn N150 |
Ralink RT2770 |
Ralink RT2720 |
1x2:2 rt2800usb, rt2870sta |
Ant. conn: | 2008-08-21 | |
| AzureWave AW-NU231 FCC ID: TLZ-AWNU231-D, TLZ-AWNU231 has external images |
USB 2.0 dongle, Male A |
abgn AN600 0a5c:bd13 |
Broadcom BCM4323 |
2x2:2 none |
OUI: 74:F0:6D Ant. conn: |
2010-07-23 | ||
| AzureWave AW-NU240 FCC ID: MDZAZW9271-240 |
USB 2.0 module, (non-standard connector) |
bgn N150 |
CoO:
|
Atheros AR9271 |
1x1:1 ath9k htc |
Ant. conn: | 2012-10-10 | |
| AzureWave AW-NU705 | USB 2.0 --, Mini PCIe |
bgn N150 |
unk. |
1x2:2 unknown |
Ant. conn: U.FL | |||
| AzureWave AW-NU706 FCC ID: TLZ-NU706 |
USB 2.0 --, Mini PCIe |
bgn N150 |
Ralink RT3070 |
1x1:1 rt2800usb, rt2870sta |
Ant. conn: U.FL | 2008-11-10 | ||
| AzureWave AW-NU706H FCC ID: TLZ-NU706 has external images |
USB 2.0 module [half], Mini PCIe |
bgn N150 13d3:3273 |
CoO:
|
Ralink RT3070 |
1x1:1 rt2800usb, rt2870sta |
OUI: 74:F0:6D Ant. conn: U.FL |
2008-11-10 | |
| AzureWave AW-XB468NF FCC ID: RAS-MT7921 Wi-Fi Certified |
M.2 2.1 module, M.2 |
abgn+ac+ax AX1800 14c3:7961 |
CoO:
|
MediaTek MT7921L |
2x2:2 none |
Ant. conn: MHF4 Flags: WiFi 6, Bluetooth 5.0 LE, WPA3, Wi-Fi Direct, WMM, Wi-Fi Agile Multiband |
2020-09-25 | |
| AzureWave AW-XB473NF FCC ID: TX2-RTL8852AE |
USB 2.0 2230, M.2 (Key A/E) 2.0 |
abgn+ac+ax AX1800 10ec:8852 |
CoO:
|
Realtek RTL8852AE |
2x2:2 rtw89 |
Ant. conn: MHF4 Flags: WiFi 6, Bluetooth 5.0, WPA3, MU-MIMO, HE80 |
2020-10-16 | |
| AzureWave AW-XB503NF FCC ID: TX2-RTL8852AE |
PCIe/USB | abgn+ac+ax AX1800 10ec:8852 |
CoO:
|
Realtek RTL8852AE |
1x2:2 rtw89 |
Ant. conn: MHF4 Flags: WiFi 6, Bluetooth 5.0, WPA3, MU-MIMO, HE80 |
2020-10-16 | |
| AzureWave AW-XB530NF FCC ID: RAS-MT7922A22M |
M.2 2.1 2230, M.2 (Key A/E) |
abgn+ac+ax AXE5400 14c3:7922 |
CoO:
|
MediaTek MT7922A |
2x2:2 none |
OUI: 14:13:33, 50:5A:65 Ant. conn: MHF4 Flags: Bluetooth 5.2 LE, WPA3, Wi-Fi Direct, WMM, Wi-Fi Agile Multiband, Wi-Fi 6E |
2021-07-08 (no FCC) | |
| AzureWave AW-XB547NF FCC ID: TX2-RTL8852BE has external images |
M.2/USB | abgn+ac+ax AX1800 10ec:b852 |
AzureWave CoO:
|
Realtek RTL8852BE |
2x2:2 rtw89 |
OUI: 20:0B:74, 94:BB:43 Ant. conn: MHF4 Flags: Wi-Fi 6, WPA3, MU-MIMO, HE80, Bluetooth 5.2 BLE |
2021-08-13 | |
| AzureWave AW-XM458MA FCC ID: TLZ-XM9098 has external images |
M.2 2.0 2230, M.2 (Key E) |
abgn+ac+ax AX1800 1a3b:2458 |
AzureWave CoO:
|
Marvell 88W9098 |
2x2:2 none |
Ant. conn: MHF4 Flags: Wi-Fi 6, WPA3, MU-MIMO, HE80, Bluetooth 5.1, Dual-Radios |
2021-10-01 |
Manuf Network Adapters
32 total devices
| Device | Interface | PHY modes |
Manuf. | Chip1 | Chip2 | MIMO | Addl. info |
FCC date |
|---|---|---|---|---|---|---|---|---|
| Abit AirPace WLP-01 FCC ID: TLZ-GE870 |
PCIe --, PCIe |
bg G54 |
AzureWave AW-GE870 CoO:
|
Atheros AR2425 |
ath5k, madwifi |
OUI: 00:15:AF Ant. conn: RP-SMA |
2007-01-24 | |
| AzureWave AW-AH397 | SDIO 3.0 module [SiP], SD (solder down) |
abgn AN300 |
AzureWave |
Marvell 88W8797 |
1x1:1 mwifiex |
Ant. conn: Flags: Bluetooth 4.0, FM radio |
||
| AzureWave AW-CB178NF FCC ID: TLZ-CB178NF |
M.2 2230, M.2 |
abgn+ac AC1200 |
AzureWave |
Marvell 88W8897 |
2x2:2 mwifiex |
OUI: 54:27:1E Ant. conn: Flags: Bluetooth 4.0, DFS |
2014-10-13 | |
| AzureWave AW-CB295NF FCC ID: TX2-RTL8822BE |
USB 2.0 2230, M.2 1.1 (Key A/E) |
abgn+ac AC1200 10ec:b822 |
AzureWave CoO:
|
Realtek RTL8822BE |
2x2:2 rtw88, rtlwifi_new |
Ant. conn: MHF4 Flags: Wave2, VHT80, MU-MIMO, Bluetooth 4.2 |
2016-08-29 | |
| AzureWave AW-CE123H FCC ID: QDS-BRCM1068 has external images |
Mini PCIe [half], Mini PCIe |
abgn+ac AC1200 14e4:43b1 |
AzureWave CoO:
|
Broadcom BCM4352 |
2x2:2 wl 6 |
OUI: 24:0A:64, 6C:71:D9 Ant. conn: U.FL Flags: Bluetooth 4.0 |
2012-10-16 | |
| AzureWave AW-CM256SM FCC ID: 2A3PA-ROCK4C, 2A3PA-RADXA-CM3 has external images |
SDIO 3.0 [module], LGA (SD) |
abgn+ac AC600 02d0:a9bf |
AzureWave CoO:
|
Cypress CYW43455 |
1x1:1 unknown |
OUI: 00:90:4C Ant. conn: U.FL |
||
| AzureWave AW-CM276NF FCC ID: UAY-W8997-M1216 has internal images |
M.2 2.0 1216, SD (solder down) |
abgn+ac AC1200 |
AzureWave |
Marvell 88W8997 |
2x2:2 mwifiex |
Ant. conn: MHF4 Flags: Wave2, MU-MIMO, Bluetooth 4.2, DFS (slave) |
2017-01-25 | |
| AzureWave AW-CM308NF FCC ID: TLZ-CM308NF |
USB 2.0 1216, M.2 1.1 |
abgn+ac AC1200 10ec:b822 |
AzureWave CoO:
|
Realtek RTL8822BE |
2x2:2 rtw88, rtlwifi_new |
Ant. conn: MHF4 Flags: Wave2, DFS, MU-MIMO, Bluetooth 4.2, short-term conf template expired |
2017-08-10 | |
| AzureWave AW-CM389NF FCC ID: TLZ-CM389NF |
M.2 2.0 1216 [module], M.2 (LGA SD) |
abgn+ac AC1200 |
AzureWave CoO:
|
Marvell 88W8897 |
2x2:2 mwifiex |
Ant. conn: MHF4 Flags: Bluetooth 4.2 LE, DFS, Datasheet |
2014-07-09 | |
| AzureWave AW-CM390SM FCC ID: TLZ-CM390SM |
SDIO 3.0 module [12x12], SD (solder down) |
abgn+ac AC600 1a3b:2390 |
AzureWave |
Cypress CYW43455 |
1x1:1 unknown |
Ant. conn: MHF4 Flags: Bluetooth 5.0, DFS (slave) |
2020-06-15 | |
| AzureWave AW-GH321 has external images |
SDIO --, SDIO (module) |
bg G54 |
AzureWave CoO:
|
Marvell 88W8686 |
libertas |
Ant. conn: | ||
| AzureWave AW-GH381 | SDIO --, SDIO (module) |
bg G54 |
AzureWave CoO:
|
Marvell 88W8688 |
Ant. conn: Flags: Bluetooth |
|||
| AzureWave AW-GU702 FCC ID: TX2-RTL8187B |
USB 2.0 --, Mini PCIe |
bg G54 0bda:8189 |
AzureWave CoO:
|
Realtek RTL8187B |
Realtek RTL8225 |
rtl8187 |
OUI: 00:22:43 Ant. conn: U.FL |
2007-02-06 |
| AzureWave AW-HM482 FCC ID: TLZ-HM482 |
SDIO 3.0 2230, SD (LGA) |
ah AH15 1a3b:2482 |
AzureWave CoO:
|
Newracom NRC7292 |
RFMD FM6901 |
1x1:1 unknown |
Ant. conn: Flags: HaLow, MCU SoC |
2021-09-28 |
| AzureWave AW-NB086 FCC ID: TLZ-NB086 has external images |
PCIe --, (non-standard connector) |
bgn N150 168c:0032 |
AzureWave CoO:
|
Atheros AR9485 |
1x1:1 ath9k |
OUI: 00:08:CA, 74:2F:68, E0:B9:A5 Ant. conn: MHF4 Flags: Bluetooth |
2011-08-23 | |
| AzureWave AW-NB110H FCC ID: PPD-AR5B22 |
Mini PCIe [half], Mini PCIe |
abgn AN600 |
AzureWave |
Atheros AR9462 |
2x2:2 ath9k |
OUI: 6C:71:D9 Ant. conn: U.FL Flags: Bluetooth 4.0 |
2012-02-03 | |
| AzureWave AW-NB114H FCC ID: TX2-RTL8723AE has external images |
Mini PCIe [half], Mini PCIe |
bgn N150 10ec:8723 |
AzureWave CoO:
|
Realtek RTL8723AE |
1x1:1 rtl8723ae, rtlwifi_new (WIP) |
OUI: 6C:71:D9, 24:0A:64, 28:C2:DD Ant. conn: U.FL Flags: Bluetooth 4.0 |
2011-12-06 | |
| AzureWave AW-NB159H FCC ID: TLZ-NB159H, TX2-RTL8723BE |
Mini PCIe 2.0 HMC [half], Mini PCIe |
bgn N150 10ec:b723 |
AzureWave |
Realtek RTL8723BE |
1x1:1 rtl8723be, rtlwifi_new (WIP) |
Ant. conn: U.FL Flags: Bluetooth 4.0 |
2013-05-08 | |
| AzureWave AW-NE121H FCC ID: PPD-AR5B97 |
Mini PCIe [half], Mini PCIe |
bgn N300 |
AzureWave |
Atheros AR9287 |
2x2:2 ath9k |
OUI: 24:0A:64 Ant. conn: U.FL |
2009-08-14 | |
| AzureWave AW-NE186H FCC ID: PPD-AR5B125 has external images |
Mini PCIe [half], Mini PCIe |
bgn N150 168c:0032 |
AzureWave |
Atheros AR9485 |
1x1:1 ath9k |
OUI: DC:85:DE, 24:0A:64 Ant. conn: |
2011-03-08 | |
| AzureWave AW-NH387 | SDIO --, SDIO (module) |
bgn N150 |
AzureWave CoO:
|
Marvell 88W8787 |
1x1:1 mwifiex |
Ant. conn: U.FL Flags: Bluetooth |
||
| AzureWave AW-NM313S FCC ID: IXMUGNAS-P3, TLZ-NM313S has external images |
SDIO 2.0 module, SD (solder down) |
bgn N150 |
AzureWave CoO:
|
Marvell 88W8786 |
1x1:1 mwifiex |
Ant. conn: | 2011-07-29 | |
| AzureWave AW-NU109H FCC ID: KA2AWNU109HA1 |
USB 2.0 [half], Mini PCIe |
bgn N150 0a5c:bd16 |
AzureWave |
Broadcom BCM4319 |
1x1:1 none |
OUI: 74:F0:6D Ant. conn: U.FL |
2010-08-27 | |
| AzureWave AW-XB547NF FCC ID: TX2-RTL8852BE has external images |
M.2/USB | abgn+ac+ax AX1800 10ec:b852 |
AzureWave CoO:
|
Realtek RTL8852BE |
2x2:2 rtw89 |
OUI: 20:0B:74, 94:BB:43 Ant. conn: MHF4 Flags: Wi-Fi 6, WPA3, MU-MIMO, HE80, Bluetooth 5.2 BLE |
2021-08-13 | |
| AzureWave AW-XM458MA FCC ID: TLZ-XM9098 has external images |
M.2 2.0 2230, M.2 (Key E) |
abgn+ac+ax AX1800 1a3b:2458 |
AzureWave CoO:
|
Marvell 88W9098 |
2x2:2 none |
Ant. conn: MHF4 Flags: Wi-Fi 6, WPA3, MU-MIMO, HE80, Bluetooth 5.1, Dual-Radios |
2021-10-01 | |
| Broadcom BCM94319SDB FCC ID: QDS-BRCM1056 |
SDIO --, SDIO (non-standard connector) |
bgn N150 |
AzureWave AW-NB066 CoO:
|
Broadcom BCM4319 |
Broadcom BCM20702 |
1x1:1 none |
OUI: E0:B9:A5 Ant. conn: Flags: Bluetooth |
2011-03-16 |
| Broadcom BCM94319SDHMB FCC ID: QDS-BRCM1057 |
Mini PCIe --, (SDIO) |
bgn N150 |
AzureWave CoO:
|
Broadcom BCM4319 |
Broadcom BCM20702 |
1x1:1 none |
Ant. conn: U.FL Flags: Bluetooth |
2011-03-31 |
| HP HSTNN-AR01 FCC ID: B94HNAR01 |
module --, module |
abgn AN300 |
AzureWave AW-AM634NF CoO:
|
Broadcom BCM4334 |
1x1:1 brcmfmac |
Ant. conn: Flags: Bluetooth |
2013-05-17 | |
| HP SDGOB-0892 (1150-7935) FCC ID: B94SDGOB0892 has internal images has external images |
USB 2.0 module, (non-standard connector) |
bgn N150 1286:203c |
AzureWave AW-GM310S CoO:
|
Marvell 88W8786U |
1x1:1 none |
OUI: 08:ED:B9, 18:F4:6A, 38:59:F9, 74:F0:6D, 78:E4:00, 7C:E9:D3, C0:F8:DA, E4:D5:3D Ant. conn: U.FL |
2009-02-04 | |
| Marvell W8997-M1216 FCC ID: UAY-W8997-M1216 has internal images |
M.2 2.0 1216, SD (solder down) |
abgn+ac AC1200 11ab:2b42 |
AzureWave AW-CM276NF |
Marvell 88W8997 |
2x2:2 mwifiex |
Ant. conn: MHF4 Flags: Wave2, MU-MIMO, Bluetooth 4.2, DFS (slave) |
2017-01-25 | |
| Radxa Wireless Module A8 FCC ID: TX2-RTL8852BE has external images |
PCIe/USB | abgn+ac+ax AX1800 10ec:b852 |
AzureWave AW-XB547NF CoO:
|
Realtek RTL8852BE |
2x2:2 rtw89 |
OUI: 94:BB:43 Ant. conn: MHF4 Flags: WPA3, MU-MIMO, HE80, Bluetooth 5.2 BLE, Wi-Fi 6 |
2021-08-13 | |
| Ralink RT5370 Reference Design FCC ID: VQF-RT3070HMC, VQF-RT5390 |
USB 2.0 --, Mini PCIe |
bgn N150 148f:5370 |
AzureWave AW-NU168H CoO:
|
Ralink RT5370 |
1x1:1 rt2800usb, rt5370sta |
Ant. conn: U.FL Flags: Wi-Fi Direct |
Network Switch
0 total devices
Cypress Wireless Modules
| Module Part Number | Wi-Fi/BT PN |
Wi-Fi/BT Support |
MCU | CPU (MHz) |
Area (mm) |
Regulatory | Linux | Interfaces | Highlights |
|---|---|---|---|---|---|---|---|---|---|
| AzureWave AW-CU289 | Cypress CYW43438 |
2.4GHz, 802.11bgn, BT/BLE | ARM Cortex-M4 / STM32F412 | 100MHz | 16x32x3.1 | No | No | SPI, I2S, USART, CAN | 1MB MCU Flash, 256KB RAM, 2MB SFlash, U.FL |
| AzureWave AW-CU287 | Cypress CYW43362 |
2.4GHz, 802.11bgn | ARM Cortex-M4 / STM32F412 | 100MHz | 16x32x3.1 | No | No | SPI, I2S, USART, CAN | 2MB MCU Flash, 256KB RAM, U.FL |
| AzureWave AW-CU307 | Cypress CYW43362 |
2.4GHz, 802.11bgn | ARM Cortex-M4 / STM32F411 | 100MHz | 16x32x3.1 | No | No | SPI, I2S, USART, CAN | 1MB MCU Flash, 256KB RAM, U.FL |
| AzureWave AW-NH650 | Cypress CYW43362 |
2.4GHz, 802.11bgn | Radio only | N/A | 8x8 | No | Yes | SDIO, SPI | SDIO interface, WiFi and BT/BLE |
| AzureWave AW-AH640 | Cypress CYW43340 |
2.4/5GHz, 802.11abgn, BT/BLE | Radio only | N/A | 9x9 | No | Yes | SDIO, UART | SDIO interface WiFi, BT/BLE Radio only |
| AzureWave AW-CH639 | Cypress CYW4339 |
2.4/5GHz, 802.11abgn /ac, BT/BLE | Radio only | N/A | 10x10 | No | Yes | SDIO, UART | SDIO interface WiFi, BT/BLE Radio only |
| Azurewave AW-AM342SM | Cypress CYW43012 |
2.4/5GHz, 802.11abgn, BT/BLE | Radio only | N/A | 12x12 | No | Yes | SDIO, UART | SDIO, UART interface, BT 5.0 |
| AzureWave AW-CM390SM | Cypress CYW43455 |
2.4/5GHz, 802.11abgn /ac, BT/BLE | Radio only | N/A | 12x12 | No | Yes | SDIO, UART | Includes Xtal |
| AzureWave AW-CM256SM | Cypress CYW43455 |
2.4/5GHz, 802.11abgn /ac, BT/BLE | Radio only | N/A | 12x12 | No | Yes | SDIO, UART | SDIO interface, Radio only |
| AzureWave AW-NB197SM | Cypress CYW43438 |
2.4GHz, 802.11bgn, BT/BLE | Radio only | N/A | 12x12 | No | Yes | SDIO, UART | SDIO interface WiFi, BT/BLE Radio only |
| AzureWave AW-NM230NF | Cypress CYW43438 |
2.4GHz, 802.11bgn, BT/BLE | Radio only | N/A | NGFF M.2 1216 |
FCC/IC/ NCC/CE | Yes | SDIO, UART | SDIO interface WiFi, BT/BLE Radio only, Module Certification |
| AzureWave AW-NM372SM | Cypress CYW43438 |
2.4GHz, 802.11bgn, BT/BLE | Radio only | N/A | 12x12 | No | Yes | SDIO, UART | Includes Xtal |
| AzureWave AW-NM288SM | Cypress CYW43362 |
2.4GHz, 802.11bgn | Radio only | N/A | 12x12 | No | Yes | SDIO | SDIO interface |
Wireless Adapters
<img src="https://wkretype.bdimg.com/retype/zoom/ff360616ee06eff9aff80714?pn=1&o=jpg_6&md5sum=0d50fe7b644d8b30db12228df4155a33&sign=1b3e45e4c3&png=0-1791&jpg=0-269518" | width=1000px >
<img src="https://wkretype.bdimg.com/retype/zoom/ff360616ee06eff9aff80714?pn=2&o=jpg_6&md5sum=0d50fe7b644d8b30db12228df4155a33&sign=1b3e45e4c3&png=1792-2292&jpg=269519-554083" | width=1000px >
Wireless Modules
|
|
NXP Wireless Modules
|
|
Nvidia
|
|
FCC ID
- FCC ID: TLZ
FCC ID Application Date Product Purpose Application Type TLZ-CU603 (2024-08-13) 802.11ax Wireless MCU with Int. Wi-Fi 6 Microcontroller Module TLZ-HM610 (2024-08-08) 802.11ah Wireless LAN Module TLZ-CU5XX (2024-07-03) 802.11ax Wireless MCU with Int. Tri-radio Wi-Fi 6 + BLE 5.3 + 802.15.4 LGA Module TLZ-HM581 (2024-06-26) 802.11ah Wireless LAN Module TLZ-HM593 (2024-06-07) 802.11ah Wireless LAN Module * TLZ-CM358SM (2024-05-15) 802.11ac WLAN with Bluetooth 5 Combo Stamp Module * TLZ-XH32X (2024-05-07) 802.11ax Wi-Fi 6 + Bluetooth 5.3 Combo SIP Module TLZ-XM549 (2023-10-20) 802.11ax 1x1 WLAN + Bluetooth 5.3 + 802.15.4 Tri-radio 12x12 LGA Module TLZ-AM497617 (2023-08-24) 802.11ac with BT 5.2 Combo Module, 802.11ac with BT 5.3 Combo Module TLZ-XM9098 (2023-05-05) 802.11ax 2x2 Wi-Fi 6 SU MU-MIMO DBC WLAN + Bluetooth 5.1 Combo Module * TLZ-XM455 (2023-05-05) 802.11ax 2x2 Wi-Fi 6 MIMO Wireless LAN + Bluetooth 5.3 Combo LGA Module TLZ-AM510 (2023-04-29) 802.11abgn 1x1 Wireless LAN + Bluetooth 5.1 Combo 12x12 LGA Module * TLZ-CU442 (2022-12-21) 802.11bgn 1T1R WLAN and Bluetooth Low Energy Microcontroller Module * TLZ-CM276NF (2022-12-01) 802.11ac 2x2 MU-MIMO Wireless LAN + Bluetooth NGFF Module * TLZ-CU544 (2022-07-26) 802.11bgn MAC/Baseband/Radio and Bluetooth 5.2 IoT Module TLZ-CM276NF (2022-07-18) 802.11ac 2x2 MU-MIMO Wireless LAN + Bluetooth NGFF Module * TLZ-XM9098 (2022-06-20) 802.11ax 2x2 Wi-Fi 6 SU MU-MIMO DBC WLAN + Bluetooth 5.1 Combo Module * ! + TLZ-CD110 (2022-04-19) 802.11ac 1T1R WLAN USB Dongle TLZ-CB511 (2022-03-31) 802.11ac WLAN 2T2R with Bluetooth 5.0 Combo Module TLZ-CM467 (2021-12-20) 802.11ac and Bluetooth 5.0 Module TLZ-HM482 (2021-09-28) 802.11ah Wireless LAN Module ! + TLZ-NM430SM (2021-09-14) 802.11bgn 1x1 Wireless LAN and Bluetooth 4.2 12x12mm Stamp LGA module TLZ-AM510 (2021-05-25) 802.11abgn 1x1 Wireless LAN + Bluetooth 5.1 Combo 12x12mm LGA Module TLZ-AM457-D (2021-04-23) 802.11abgn 1x1 Wireless LAN + Bluetooth 5.1 Combo LGA Module TLZ-CU488 (2021-04-07) 802.11abgn 1T1R WLAN and Bluetooth Low Energy Microcontroller Module TLZ-NM512 (2021-03-29) 802.11bgn Wireless LAN and Bluetooth Module TLZ-NM372SM (2021-01-29) 802.11bgn Wireless LAN and Bluetooth Module TLZ-CU484 (2020-12-08) 802.15.4 and Bluetooth LE 5.0 Wireless Microcontroller Stamp LGA Module TLZ-CU442 (2020-07-30) 802.11bgn 1T1R WLAN and Bluetooth Low Energy Microcontroller Module TLZ-CM276NF (2020-07-30) 802.11ac 2x2 MU-MIMO Wireless LAN + Bluetooth Module (NGFF) TLZ-CU429 (2020-07-28) Bluetooth 5.1 (LE Only) Stamp Module + Cortex-M33 + Flash + Antenna TLZ-CU462 (2020-07-13) 802.11bgn 1T1R WLAN and Bluetooth Low Energy Microcontroller Module TLZ-CM390SM (2020-06-15) 802.11ac Wi-Fi with Bluetooth 5.0 Combo Stamp Module TLZ-CU427 (2020-04-24) 802.11bgn MAC/Baseband/Radio and Bluetooth 4.2 IoT Module (Int Antenna) TLZ-CM358SM (2020-02-20) 802.11ac WLAN with Bluetooth 5 Combo Stamp Module TLZ-CB250NF (2019-11-26) 802.11ac 2x2 MU-MIMO WLAN + Bluetooth 5.0 Module (M.2 2230) TLZ-CM382 (2019-08-22) 802.11ac MAC/Baseband/Radio and Bluetooth 5.0 Module TLZ-NM191NF (2019-07-11) 802.11bgn Wireless LAN Module TLZ-CU300 (2019-05-30) 802.11bgn WLAN Microcontroller Module TLZ-CM389NF (2019-02-01) 802.11ac 2x2 MIMO WLAN + Bluetooth + NFC Module (NGFF) TLZ-CU345 (2018-12-10) 802.11bgn + Bluetooth 5.0 LE WLAN/BT Microcontroller Module TLZ-CM2XXNF (2018-11-12) 802.11ac Wireless LAN and Bluetooth Combo Module (NGFF M.2) TLZ-CU362 (2018-11-06) Bluetooth 5.0 LE Stamp Module TLZ-NM333 (2018-05-14) 802.11bgn 1x1 Wireless LAN Module TLZ-CM299 (2018-02-08) 802.11ac 1x1 Wireless LAN + Bluetooth Module TLZ-CU302 (2017-10-06) 802.11bgn WLAN + Bluetooth 4.2 LE Microcontroller Module TLZ-NM230NF (2017-08-29) 802.11bgn WLAN and Bluetooth Combo Module (M.2 1216) TLZ-CM308NF (2017-08-10) 802.11ac WLAN 2T2R and Bluetooth 4.2 Combo Module (M.2 1216) TLZ-CB178NF (2017-07-28) 802.11ac 2x2 MIMO WLAN & Bluetooth Module (M.2) TLZ-CM286NF (2017-06-28) 802.11ac 1x1 WLAN + Bluetooth Module (NGFF) TLZ-CU277B (2016-06-14) 802.11bgn + Bluetooth 4.0 HS Smart Energy Module TLZ-AM691NF (2015-11-17) 802.11abgn WLAN and Bluetooth Combo Module (LGA) TLZ-CU277 (2015-06-09) 802.11bgn + Bluetooth 4.0 HS Smart Energy Module
